Maxview MXL001 Installation & Benutzeranleitung
Quicklinks
HOME ENTERTAINMENT ON THE MOVE
INSTALLATION & USER INSTRUCTIONS
INSTALLATION & BENUTZERANLEITUNG
INSTALLATIE-INSTRUCTIES EN GEBRUIKSAANWIJZING
INSTALLATION ET MODE D'EMPLOI
MXL001
UK - Maxview Limited
I Common Lane I Setchey I King's Lynn I Norfolk I PE33 0AT I England
Tel +44 (0) 1553 813300 I Fax +44 (0)1553 813301 I Email info@maxview.co.uk I Website www.maxview.co.uk
D - Maxview Vertriebs GmbH
I Augsburger Strasse 11 I D-82291 I Mammendorf I Germany
Tel +49 (8145) 8840 I Fax +49 (8145) 8845 I Email info@maxview.de I Website www.maxview.de
D
NL
F
UK
NL - OCS Recreatie Groothandel B.V.
I Amarilstraat 40 - 7554 TV Hengelo (OV) I Netherlands
Tel +31(0) 74 2455680 I Fax +31(0) 74 2439655 I Email info@ocs-recreatie.nl I Website www.ocs-recreatie.nl
MXL001L Iss 1
Verwandte Anleitungen für Maxview MXL001
Inhaltszusammenfassung für Maxview MXL001
- Seite 1 UK - Maxview Limited I Common Lane I Setchey I King’s Lynn I Norfolk I PE33 0AT I England Tel +44 (0) 1553 813300 I Fax +44 (0)1553 813301 I Email info@maxview.co.uk I Website www.maxview.co.uk D - Maxview Vertriebs GmbH I Augsburger Strasse 11 I D-82291 I Mammendorf I Germany Tel +49 (8145) 8840 I Fax +49 (8145) 8845 I Email info@maxview.de I Website www.maxview.de...
- Seite 2 I THANK YOU For your own records - Please fill in the following, as this information Thank you for choosing the Omnisat 66 Manual Mast Satellite System. The Omnisat 66 has been designed for may be required if a problem with the system should occur permanent fixing to the roof of your vehicle.
- Seite 3 NOTES - HINWEIS - OPMERKINGEN - NOTES I IMPORTANT INFORMATION - PLEASE READ ADVICE & WARNINGS I On unpacking unit check for transport damage I On installation personal safety should be considered when using power/hand tools and working at height I Use straps or tie down system if the vehicle is being towed or moved at speed in a backwards direction.
- Seite 4 Entfernung des Anlagengehäuses zustande kommen). Ihre gesetzlich festgelegten Rechte werden damit nicht beeinträchtigt. I Tritt ein Problem mit diesem Produkt auf, kontaktieren Sie den Maxview-Kundendienst unter +49 (8145) 8840. Halten Sie für Ihren Anruf die folgenden Informationen bereit: Ihren Name, Adresse, Telefonnummer, Nummer des Modells und Seriennummer Kaufdatum, Klare und...
-
Seite 5: Troubleshooting
TROUBLESHOOTING I PRODUCT ASSEMBLY DIAGRAM EXPLOSIONSZEICHNUNG Problem: The elevation and park stops seem hard to find on turning handle. Solution: The stops are internal and are soft stops, so as soon as you feel some resistance this will ONDERDELENSCHEMA be the park or elevation limit stop. Do not force the handle, as this will cause damage to the unit. SCHEMA D’ASSEMBLAGE DES COMPOSANTS No signal being received Problem:... - Seite 6 I SPARES LIST ERSATZTEILE ONDERDELENLIJST LISTE DES PIECES DE RECHANGE REAR HINTERSEITE DE ACHTERKANT ARRIÈRE Dish Antenne (Spiegel) Schotel Parabole I INSTALLATION INSTRUCTIONS I INSTALLATIONSANLEITUNG I INSTALLATIEHANDLEIDING I INSTRUCTIONS D’INSTALLATION Decide where you wish to mount your satellite system, taking into account obstacles The inside wall of a wardrobe is the LNB17 both on the roof and inside the vehicle.
- Seite 7 Stel de kanteling en azimut traag in totdat Wanneer de satellietschotel correct is uit- Voor het rijden draait u de mast totdat de het beeld verschijnt. Een Maxview Sat- gelijnd, draait u de moersleutel rechtsom gele stippen uitgelijnd zijn met elkaar...
- Seite 8 Place metal satellite. E.g ASTRA 2. A Maxview compass* required. Turn the elevation handle to to release the clamp. 10mm from the edge.
- Seite 9 Dish Alignment I USER INSTRUCTIONS Inside the vehicle, loosely screw the From the roof, feed coaxial cable through From the roof, push the rubber seal Turn on the TV and satellite receiver. sleeve, then push the mast through the plastic retaining nut onto the sleeve. over the sleeve.
