Fuel HT 200 Benutzerhandbuch Seite 31

Part No.
28 Screw M5x20L
29 Flat washer ø10.3xø25x1.5t
30 Allen bolt M4x10L
31 Self-tapping screw ST4.2x12L
32 Self-tapping screw ST4.2x20L
33 Magnetic
34 Axle for main frame
35 Flat washer ø5.2xø18x1.5t
36 Pulley
37 Plastic washer ø6.5xø13x0.5t
38 Nylon nut M10x8t
39 Flywheel
40 Axle for pulley 2
41 Idler
42 Stationary plate
43 Hex head nut M10x8t
44 Hex head nut M6x5t
45 Nut M10x8t
46 Screw M6x10L
47 Tension cable
48 Grommet 1
49 Flange nut M10x7tx1.25P
50 Hex head bolt M6x30t
51 C-clip
52 Wave washer
53 Adjustor set
54 Spring
55 Flat washer ø8.3xø25x2t
56 Bearing 6003ZZ
57 End cap for crank
58 Bushing
59 Screw M5x10L
60 Pulley 2
61 Bearing bracket
62 Bumper
63 Bushing ø16xø22.3xø30x12.5H
Description
31
Q'ty
1
1
1
6
11
1
1
1
1
1
1
1
1
1
2
2
1
1
6
1
1
2
1
6
1
2
1
6
2
2
1
1
1
2
1
6
