INTRODUCTION:

CONTROL FEATURES

LED COLOUR BAR
(CLBARL10RGBA/WH)
• 2-/ 3-/ 4-/ 6-/ 19-channel DMX
• Blackout/Dimmer
• Individual control of Red, Green, Blue and Amber LEDs
FEATURES
• 252 LEDs
• Ultra Bright 10mm RGBA LEDs
• Colour change speed and strobe effect adjustable via control panel
• Sound control via internal microphone
• Multi-colour changes
• RGBA Colour mixing
• Master/Slave functions
• Rugged compact housing
• Double bracket
• Power consumption: 40 W
• Beam angle: 30 degrees
• Long life LEDs
OPERATING INSTRUCTIONS
The Cameo LED BAR is a DMX-512 controllable, full RGBA colour mixing spot made up of high efficiency and
super bright 10mm LED's. There are four colour groups (red, green, blue and amber) whose intensity can be con-
trolled individually allowing the creation of an unlimited range of colours. The Cameo LED BAR light will operate
in Stand-alone, Master/Slave, Sound activated and via DMX-512 control.
