Opening of the rollator
- Push the red button which is locking the seating tubes (See the image shown on the right side).
- Hold both seat tubes and simultaneously push them down until you hear a "click" sound of the
locking mechanism of the frame.
- Try to pull the seat tubes back up to fold the frame. If this is not possible the frame is opened and
secured correctly.
•
After unfolding or assembling the rollator always ensure that the seat support is securely locked by
the pulling strip mechanism for securing the lock and that the frame does not move anymore.
•
Always ensure that both arm support inner tubes are securely locked in the main frame tube with
the two wing knobs to prevent the accidental sliding in of the inner tubes when forced.
•
Always test that both armrests are set on the same height and that they are properly fastened on
top of the inner tube. It is not allowed to use a defective device.
•
Always make sure that after everything has been secured, nothing can move.
•
Always test to see that the rollator and attachments are properly and safely locked in place
BEFORE using.
•
Failure to follow these warnings can result in personal injury.
Folding
- Disconnect the stabilization strap (3)
- Disconnect the backrest in the middle (4)
- Pull at the pulling strap on the seat to fold the rollator.
- Fold the rollator until the red button locks
- Before the rollator is folded and locked, one of the forearm supports must be set to a minimum
of three steps higher. See pictures 2 and 3.
