8 Label Example
The product label is located on the inside of the side frame.

9 Technical data

NAVIGATOR Air – Outdoor rollator with forearm support
Frame size
Recommended user height
Max. users weight
Total weight (without shopping bag)
Weight of shopping bag
Height adjustable forearm supports
Forearm supports with horizontal rotating
Distance between forearm supports
Distance between the handgrips (straight position)
Total height, unfolded (min-max)
Length
Width opened
Width folded
Height folded (minimum)
Seat width
Seat height
Seat depth
Max. load of the bag
Brakes
Wheels (diameter x width)
Turning radius
Side frame tube diameter
Inner tube diameter of the forearm supports
Used materials and surface treatment:
- Side frame
- Inner tube
- Cross
- Wheels
- Forearm support
- Hand grips
- Brake handles
- Seat
- Bag
05 / 2020
2 x maneuver hand brakes with parking function
Front: 285 x 44 mm – Black SOFT PU tire
Rear: 235 x 44 mm – Black SOFT PU tire
50 x 25 mm (triangular)
40 x 16 mm (triangular)
Aluminium (powder coated)
Aluminium (anodized)
Aluminium (powder coated)
PA + 15% GF and PU tire
PU
Soft TPE
PA + 30% GF
PVC coated / Polyester
Polyester
10/23
Large
140-185 cm
200 kg
12 kg
0,4 kg
87-110 cm (9 steps)
22,5° or 45° inward
40 cm
56 cm
96-120 cm (1-9 steps)
77 cm
71 cm
31 cm
99 cm
53 cm
62 cm
18 cm
5 kg
96 cm
NAVIGATOR Air
