Technical Specification; Maintenance - Berner BHFB 05 Bedienungsanleitung

TECHNICAL SPECIFICATION

Code
nominal voltage
Charging voltage
Charging current
Cooling
Charging characteristic curve
Battery types
Battery capacity
weight

MAINTENANCE

The charger is maintenance-free. The charger must not be opened. This will invalidate
the warranty. If the mains cable or the charging cables are damaged, they must be
replaced. The charger housing can be cleaned with a dry cloth. Disconnect the mains
plug before cleaning.
Art. 120780 BHFB 05
220V to 240V 50/60 Hz
max. 14.8 V
5 A
Via housing
IUoU
Lead-acid, lead-GEL, AGM
10-200 Ah
0,85 lbs
1. Battery Clip Cable Assembly
2. Ring Terminal Cable Assembly
3. LED Indicators
4. Mounting Holes
(EN)
