AXIS 225FD Installation Guide
Description
Tamper-proof
screws
Dome casing
Unit casing
Serial number (S/N)
The serial number is required
during the installation.
Notes:
• Use cables and conduits that are suitable for the installation and that are in compliance
with the IP66 rated, outdoor-proof, vandal resistant design of the AXIS 225FD.
• Conduit dimensions: NPT 3/4" -14 (Pipe thread).
Important!
If the AXIS 225FD is not mounted according to the instructions, there may be problems with
moisture which is not covered by warranty.
Downloaded from www.Manualslib.com
Conduit hole
(side)
Conduit hole
(bottom)
Cable
Cables gland
manuals search engine
Power connector block
7
I/O terminal
block
(see table 1)
Network
connector
LED
indicators
1 2 3 4
(see table 2)
Rubber
Outer
plug
ring
Page 5
