Specification

Battery
Non-replaceable Lithium battery.
Expected life 10 yearat 20°C
Display
8 digit black LCD, 7mm characters
Count Range
99999999 - rollover to 0
Operating temperature
-10°C to +60°C
Storage temperature
-20°C to +60°C
WARNING
THIS UNIT CONTAINS A LITHIUM BATTERY AND MUST NOT BE DISPOSED OF
IN A FIRE OR EXPOSED TO TEMPERATURES BELOW -20 C OR ABOVE +70 C.
Connections
24cm (9.45")
Black
Green
Yellow
Brown
Blue
2
internal
resistor
1
Enable Reset
Disable
Button
(TTL/CMOS)
4
internal
resistor
1
Low Speed Count
<=30Hz
(Contact Closure/
Open Collector)
2
14:23 Page 2
Altitude
Up to 2000m
Relative Humidity
80% max up to 31°C, decreasing to
50% max at 40°C
Sealing
Front panel sealed to IP65 when used
with clip mount and gasket provided.
1
Common
2 Enable Reset Button
External Reset
3
Low Speed Count Input
4
High Speed Count Input
5
+V
External Reset
<=18V
(Contact Closure/
0.7V
Open Collector)
Enable
+V
High Speed Count
(TTL/CMOS)
<=18V
=>15mS
0.7V
Draft
}
} 18V
} max
}
+V
3
internal
resistor
1
<=18V
=>15mS
0.7V
+V
5
internal
resistor
1
<=10KHz
<=18V
=>50 S µ
0.7V
