Conventional electric door chime
If someone rings your video doorbell, you will immediately receive a
push notification with sound/vibration on your smartphone or tablet. In
addition the video doorbell comes with a zero-potential relay contact for
connecting a conventional electric door chime inside the building. The
relay contact can be used to activate the separate operating voltage of
the door chime or the door chime via its trigger input. If the operating
voltage of the door chime is activated, it should not be greater than 24V
(AC/DC). The power consumption should not exceed 1A. The video
doorbell does not provide its own power supply for the door chime. This
is provided through the separate power supply of your conventional
door chime. Should you have any questions, please contact the
manufacturer of your door chime. You can find compatible door chimes
and a sample wiring diagram at www.doorbird.com/support
Conventional door opener button
If an electric door opener is connected to the video doorbell, the door
opener can be opened by App and also be directly controlled via a zero-
potential button to be found in the interior of the building, i.e. a door
opening button. In addition, the door opener button is to be connected
to the connection terminal provided. You can find compatible door
opener
buttons
and
www.doorbird.com/support
Step 6: Dowels
If the exterior wall of the house is not made of wood, you should drill four holes 5 mm in diameter in
the wall and then place the dowels provided into the boreholes. If the exterior wall of the house is
made of wood, you will usually not require any dowels. There are special dowels for assembling the
video doorbell on an insulating wall, e.g. Fischer insulating dowels. Please check with your insulating
material manufacturer regarding which dowels they recommend.
Step 7: Attach the mounting plate
Put the wires that you would like to connect to the video doorbell through the opening in the
mounting plate provided. Position the mounting plate against the exterior wall of the house and use
the screws provided to position it in the dowels or on the wall.
Step 8: Preparing the wires
Remove about 5 mm of insulation material at the end of the wires that you would like to connect to
the video doorbell.
Step 9: Connecting the wires
It is possible to connect the video doorbell conveniently and safely via a connection terminal with
screws on the reverse of the video doorbell. You can use the small Phillips screwdriver provided with
the video doorbell to loosen or tighten the screws. Please be careful when tightening the screws, the
connection terminal is fragile because of its small form-factor. The individual contacts on the
connection terminal are labelled on the reverse of the casing. Some connectors on the connection
terminal may come provided by us with approximately 15 cm long wires. You can simply use pliers to
connect these directly to your own wires via crimp connectors. Please remove any wires on the
connection terminal that you do not need. You can also connect your wires directly to the connection
panel using a small screwdriver (included).
a
sample
wiring
Two insulated wires.
Two insulated wires.
diagram
on
5
