Characteristic Values; Overview - AWG M0,4 Originalbetriebsanleitung

AWG I Operating manual I Fittings I
3.4

Characteristic values

Max. flow rate
Foam coefficient
Foam throw distance
Optimum operating pressure
Admixing rate
Max. operating pressure
Operating temperature
* measured using STHAMEX
3.5

Overview

1 Conversion screen
2 Foam tube
3 Type plate
4 Full cone nozzle
5 Inductor (not visible)
6 Valve housing
Fig. 1 Overview AWG Medium expansion foam pistol M0,4
28 / 40
Medium expansion foam pistol M0,4
® -K 1% F-15 #9143 STHAMEX
ENGLISH
Medium expansion foam
45 l/min (6 bar)
60-fold*
5 m*
Approx. 3 to 5 bar
1 % or 3 %
16 bar
- 20 °C to + 60 °C
7 Fixed coupling
8 Handle
9 Trigger
10 Pick tube
11 Foam agent container
DESCRIPTION
® 3% F-15 #9348
