SPECIFICATIONS

Channels (Favourites + Instant): ......................................................... 183
Frequency Range (in MHz) See page 5
Sensitivity (12 dB SINAD) (Nominal)
78.0000 MHz (FM) ........................................................................... 0.5 μV
84.1250 MHz (FM) ........................................................................... 0.4 μV
90.0000 MHz (FMB) ........................................................................ 0.8 μV
107.5000 MHz (FMB) ...................................................................... 0.9 μV
118.8000 MHz (AM) ........................................................................ 0.4 μV
127.1750 MHz (AM) ........................................................................ 0.4 μV
135.5000 MHz (AM) ........................................................................ 0.4 μV
138.1500 MHz (FM)......................................................................... 0.3 μV
162.4000 MHz (FM)......................................................................... 0.3 μV
173.2250 MHz (FM)......................................................................... 0.3 μV
406.8750 MHz (FM)......................................................................... 0.3 μV
453.2500 MHz (FM)......................................................................... 0.3 μV
511.9125 MHz (FM)......................................................................... 0.3 μV
Operating Temperature Range
Normal .............................................................................. –20°C to +60°C
Scan Rate: .......................................... 30 channels per second (Nominal)
IF Rejection (at 162.4 MHz)............................................. 60 dB (Nominal)
IF Frequencies (Nominal)
1st IF ....................................................................................... 70.950 MHz
2nd IF ........................................................................................... 450 kHz
Audio Output ................................................................ 490 mW maximum
Built-in Speaker .......................................................... 32 mm dia, 24 ohm
Dynamic Type
Current Drain
Squelched ........................................................................................ 60 mA
Full Audio Output (Light off)........................................................... 180 mA
Power Requirements 3 AA Alkaline Batteries (4.5V DC),
or (optional) 3 AA Rechargeable Ni-MH Batteries (3.6V DC)
Antenna .................................................................. 50 ohms (Impedance)
External Sockets
Antenna Connector .......................................................BNC Type
Ext. Earphone Jack ...................................3.5 mm stereo/mono type
Size (without antenna and belt clip):
......................................................... 53mm (W) x 28mm (D) x 104mm (H)
Weight (without Antenna and battery): ............................................. 100 g
Features, specifications, and availability of optional accessories are all
subject to change without notice.
