ArSilicii AL-BK20 Bedienungsanleitung Seite 10

Connections
Pin Description
JP16 Solar Panels Control (GREEN)
1 Engine Battery
2 Aux Battery
3 Loads
4 Negative
JP3 Webasto/Sep (RED)
1 WEBASTO Positive
2 STEP Positive
3 Negative
4 Negative
JP5 User
1,4,5,7,8 User Loads Positive
2,3 User Loads Positive
6 External Light Positive
10,11 D+ positive (max 0,6A)
9 User Loads Positive
12 Water Pump Positive
JP14 Left Side Markers
1 Side Markers Positive
2 Negative
JP6 D+ and Grid Presence
1 D+ Positive Signal
2 Grid Presence Signal
JP13 Car Body Computer inputs
1 Not Used
2 Negative D+ Input
3 Positive CH+ Input
4 Negative Side Markers Input
J4 positive D+ output
1 Positive D+ (max 0.75A)
JP11 Control Panel
Use for control panel connection only!
J1 Input I ENGINE Battery
J2 Input II AUX Battery
J3 NEGATIVE input
ArSilicii
Tel. +39 0577 988316
F2(10A)
F6(10A)
F8(10A)
F5(10/20A)
F6 (10A)
F10 (10A)
F9 (5A)
F9 (5A)
F8 (10A)
F8 (10A)
F2(10A)
Via Sardegna,11 Loc. Fosci - 53036 Poggibonsi (Siena) Web:
Fax. +39 0577 988449 info:
Power Distribution Unit v11
Pin
JP2 Light (BLACK)
1 LIGHT 2 positive
2 LIGHT 1 positive
3 Negative
4 Negative
JP4 FRIGO (WHITE) (4 poles)
1 Positive battery
2 D+ Positive
3 Positive battery
4 Negative
JP4 FRIDGE (BLACK) (3 poles)
1 Negative
2 Positive D+
3 Positive battery
1,2,3,4,5 Negative
6,7,8,9 Negative
JP15 Right Side Markers
1 Side Markers Positive
2 Negative
JP9 Water levels S1
1 Negative water Levels
2 Water level sensor #2
3 Water level sensor #3
4 Water level sensor #4
5 Negative
6 Full Tank signal
JP8 Water levels S2
1 Negative water Levels
2 Water level sensor #2
3 Water level sensor #3
4 Water level sensor #4
JP7 Water levels S3
1 Negative water Levels
2 Water level sensor #2
3 Water level sensor #3
4 Water level sensor #4
