• The actuator (channel) is now assigned with this
• Test the assignment by pressing the respective
• If you want to assign another button input to
Depending on the actuator, button inputs are taught
differently:
Actuator
Switch actuator,
Dimming actuator
Blind actuator
28
Downloaded from www.Manualslib.com
bus) that you want to assign to the actuator
(channel).
switch input and the channel LED goes dark on
the actuator.
button. The actuator (channel) should react
according to the configuration of the button
input.
the actuator (channel), repeat this procedure.
manuals search engine
Button behavior
Taught buttons behave like
toggle switches
Depending on whether teach
mode on the actuator was
triggered with the ▲- or
▼- button, the button to be
taught is taught as "Open"
or "Close", not as a toggle
button.
