Dismantling / Jumper Settings
Please note:
In the following, the internal settings of the DHA V590 are discussed.
For changing these, a TORX T10 screwdriver is required and you should by all means
PULL THE MAINS PLUG !!!
Only thereafter the settings can be altered without any hazard.

Dismantling

1. Screw off eight screws from the top of the case
2. The upper lid is situated in a rabbet of the front panel
Lift the lid on the back end and slide it out.
3. Make your settings
4. Assemble the unit in opposite order
