ABB PSE210 Serviceanleitung

Vorschau ausblenden Andere Handbücher für PSE210:

Diese Anleitung herunterladen

—

S e r v i c e i n s t r u c t i o n

Softstarter spare part

PSE210...PSE370-1

Replace the SCR's

SCR's

Seite 1 — S e r v i c e i n s t r u c t i o n Softstarter spare part PSE210...PSE370-1 Replace the SCR’s SCR‘s...
Seite 2: Safety Information
Safety information Important information: A qualified electrician must carry out installation, commissioning and service on the product by following installation standards and regulations. The product user hazardous voltage that can cause death or serious injury. Always disconnect power before working on equipment. Do not touch terminals when voltage is applied, output terminals can have live voltage even when the device is in off position.
Seite 3 M6 x 25 Hexagon no.8 Hexagon no.8 M10 x 25 M10 x 25 Tx 40 (8 Nm) Tx 30 PSE210 M8 x 16 Tx 40 M6 x 25 M8 x 40 1SFC132378M0201 | Service instruction - Replace the SCR’s |...
Seite 4 Service instruction - Replace the SCR’s Tx 25 M5 x 18 PSE210 Use 1SFA899012R1001 Kit PSE250...370 for changing SCR´s Tx 25 (3 Nm) PSE250...PSE370 Tx 30 (8 Nm) M5 x 18 Hexagon no.8 (12 Nm) M6 x 25 M10 x 25...
Seite 5 Service instruction - Replace the SCR’s Tx 20 (1,5 Nm) M4 x 80 1SFC132378M0201 | Service instruction - Replace the SCR’s |...
Seite 6 — ABB AB, Control Products SE-721 61 Västerås Sweden E-mail: sales@se.abb.com new.abb.com/low-voltage/products/softstarters © Copyright 2019 ABB. All rights reserved. Specifications subject to change without notice.
