CONNECTORS AND INDICATORS

EXPRESSlink

Rear side, USB socket

Software and Programming cable overview:

Please refer to the software and hardware specifications in the back of
this manual to see which fitting modules and programming cables are
compatible with EXPRESSlink
The programming cables mentioned are cross compatible with all prod-
ucts (from all manufacturers) which can be programmed with EXPRESS-
link . For further details please refer to the fitting software documenta-
3
tion.
