IBM
Model
Number
9851 Note 2A: (1) NEMA L6-30R to IEC 320-C20P, 6 ft
Note 2B: (1) IEC 320-C19 to NEMA L6-30P, 1.5 ft
9855 Note 2A: (1) IEC 309-CEE17R, 2-pole, 3-wire, 32A to IEC 320-C20P, 2.5m
Note 2B: (1) IEC 320-C19R to IEC 309-CEE17P, 2-pole, 3-wire, 32A, 0.6m
IBM
Model
Number
9800 NEMA L6-30P
9801 R&S 3750
9822 PDL 250V, 30A
9823 IEC 309-CEE17, 2-pole, 3-wire, 32A
9824 NEMA L6-30P
9826 PDL 250V, 30A
9835 KP 250V, 30A
9852 NEMA L6-30P
9856 IEC 309-CEE17, 2-pole, 3-wire, 32A
9862 NEMA L6-30P
9864 R&S 3750
9865 R&S 3750
9869 PDL 250V, 30A
9870 PDL 250V, 30A
9873 KP 250V, 30A
9986 NEMA L6-30P
9987 R&S 3750
Powerware ® 5125 Installation Guide for IBM Applications
Downloaded from www.Manualslib.com
:
NOTE 1 Rack Interconnect Cords: IEC 320-C13 to C14 supplied with rack devices.
:
NOTE 2 UPS Jumper Cords:
Description
:
Rack Power Cords:
NOTE 3
Description IBM Type
Type 12
Type 40
Type PDL (Wilco)
Type 46
Type 12
Type PDL
Type KP
Type 12
Type 46
Type 12
Type 40
Type 40
Type PDL
Type PDL (Wilco)
Type KP
Type 12
Type 40
:
164201356 B Uncontrolled Copy
manuals search engine
IBM IBM Part
Type Number
Type 12 yp 40H3018
Type 46 yp 17G1865
IBM Part
Country
Number
11F0113 Various
46F4594 Various
11F0106 Required for: Australia
21H7693 Various
11F0113 Many AFE countries
11F0107 Required for: New Zealand
87G6067 Required for: Korea, China
11F0113 Various
21H7693 Various
11F0114 Required for: Chicago – United States
46F4594 Various
46F4593 Required for: Chicago – United States
11F0107 Required for: New Zealand
11F0106 Required for: Australia
87G6067 Required for Korea, China
11F0114 Required for: Chicago – United States
46F4593 Required for: Chicago – United States
