LCD Panel:
Display
Backup time information
Fault information
Mute operation
Output & Battery voltage information
Load information
Mode operation information
Downloaded from www.Manualslib.com
Function
I ndicates battery discharge time in numbers.
H: hours, M: minutes, S: seconds
I ndicates that the warning and fault occurs.
I ndicates the fault codes, and the codes are listed in details in section 3-9.
I ndicates that the UPS alarm is disabled.
I ndicates the output voltage, frequency or battery voltage.
Vac: output voltage, Vdc: battery voltage, Hz: frequency
I ndicates the load level by 0-25% , 26-50% , 51-75% , and 76-100% .
I ndicates overload.
I ndicates the load or the output is short.
I ndicates the UPS connects to the mains.
I ndicates the battery is working.
I ndicates the bypass circuit is working.
I ndicates the ECO mode is enabled.
I ndicates the I nverter circuit is working.
I ndicates the output is working.
