Flash Digi 2 RF Handbuch Seite 10

CONTENTS
1
Inserting or re-inserting the batteries
Setting to current time and day
Temperature setting
Programming
Programme reading
"Auto" automatic mode
"Manu" manual mode
Temporary temperature modification
Prolonged absence mode (holidays)
Your installation maintenance signal
Installer's guide
Inserting or re-inserting the batteries
This clock thermostat is equipped with a warning light to indi-
cate when the batteries need replacing. As soon as this indi-
cator lights up at the bottom right-hand side of the display
panel, replace the batteries (use two 1.5V UR6 alkaline batte-
ries - life is approximately 12 months):
The device remains programmed for 60 seconds while batte-
ries are being replaced.
!
Before beginning the program-
ming of the device, please slide
cover down and press RESET with
the tip of a pen.
Setting current time and day
- You are putting the device into opera-
tion for the first time.
- You have just pressed the RESET button
(see above).
- "12:00" appears and the pointer
flashes under day 1.
u
Auto Manu 1 2 3 4 5
+
-
DAYS PROG
1-7 P1-P4
Set the time using the +/– buttons (the numbers run off more
quickly when the button is pressed continuously).
Set the current day by pressing several times on the
1-7 button. A pointer appears under the corresponding day
(1=Monday, 2=Tuesday, 3=Wednesday, etc.)
Validate with the OK button
If you wish to change the time or the day, press the MODE
button until the pointer appears under the clock sign and
continue as above for points ,
Functions and program of the RF Digi 2
+/– buttons for
adjusting settings
Indicator for
temperature level
or "reduced"
(1=Monday, 2=Tuesday....
Temperature setting
Comfort and reduced temperatures are pre-set :
Comfort = 20°C Reduced = 16°C.
+
-
Modification of comfort temperature
Press the comfort button
Modify the temperature with the +/– buttons
Validate with OK
22 23 24 Modification of reduced temperature
Press the reduced button
000
Modify the temperature with the +/– buttons
h
Res
Validate with OK
Programming
1 2 3 4
You can programme your week according to 4 programme
settings:
P1, P2, P3
▲
P4
6 7
MODE
MODE P1 = Comfort temperature from 6 a.m. till 11 p.m.
Reduced temperature from 11 p.m. till 6 a.m.
0 1 2 3
0000
OK
h
Res
!
The standard allocation of P1 is to 7 days of the week. If
this corresponds to your life style, stay in automatic mode.
Otherwise, continue.
P2 = Comfort temperature from 6 a.m. till 8.30 a.m. and
from 4.30 p.m. till 11 p.m.
Reduced temperature from 8.30 a.m. till 4.30 p.m. and
from 11 p.m. till 6 a.m.
0 1 2 3
P3 = Comfort temperature from 6 a.m. till 8.30 a.m., from
11.30 a.m. till 1.30 p.m. and from 4.30 p.m. till 11 p.m.
Reduced temperature from 8.30 a.m. till 11.30 a.m.,
from 1.30 p.m. till 4.30 p.m. and from 11 p.m. till 6 a.m.
and .
0 1 2 3
P4 = Blank programme allowing you to create 3 comfort
temperature periods and 3 reduced periods for each
day of the week.
"Reduced"
temperature
"Comfort"
temperature
Auto Manu
+
°c
°c
-
0 1 2 3
current
DAYS PROG
"comfort"
1-7
P1-P4
Days of the P1 to P4
week selection programme
selection
7=Sunday)
Auto Manu 1 2 3 4 5 6 7
c
°c
°c
c
0000
DAYS
PROG
OK
1-7 h
P1-P4
°c
°c
PROG
P1-P4
are pre-recorded and cannot be modified.
is blank and allows you to create a personalized
programme varying according to the day of the
week.
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Pointer Ambient
indicating day temperature
of the week
1 2 3 4 5 6 7
°c
timer
days
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0000
OK
Comfort Reduced Validation
temperature temperature
setting setting
Selection of an existing P1, P2 or P3 programme for a day of the
week (in programming mode all modifications are automati-
cally validated).
Example - P2 for Wednesday
Auto Manu
+
°c
MODE
°c
-
0 1 2 3 4 5
DAYS
PROG
1-7 P1-P4
Res
Press the PROG P1-4 button to go into programming mode.
The N° of the programme assigned to the day flashes on the
right-hand side of the display panel.
Press the DAYS 1-7 button until the pointer
under the day you wish to programme (Wednesday in our
example).
Press the PROG P1-P4 button until the P2 programme
number flashes in the right side of the screen.
Press the OK button to validate. The following day is auto-
matically proposed.
Creating a P4 programme
A 24-hour profile composed of 48 thermometers at the bottom
of the display panel allows your programme composition to be
easily viewed.
A half-empty thermometer corresponds to 30 minutes at
reduced temperature.
A full thermometer corresponds to 30 minutes at comfort
temperature.
Example - programming 3 temperature periods for Friday:
6 a.m. till 8 a.m., noon till 2 p.m. and 6 p.m. till 10 p.m.
Auto Manu
+
°c
°c
-
0 1 2 3 4
0 1 2
DAYS
PROG
1-7 P1-P4
From the "Auto" mode press the PROG P1-P4 button
Press the DAYS 1-7 button until a pointer appears under the
day you wish to programme (Friday in our example).
Press the PROG P1-P4 button until the P4 programme
number flashes in the right side of the screen. Your display
panel indicates time as 00:00 and the first thermometer
flashes on the 24-hour profile.
Warning light
Heating
to indicate
start-up indicator
battery wear
Mode
selection
Prolonged
absence
MODE
(holidays)
Viewing of
"comfort" and
"economical"
periods"
h
Res
Hour RESET
counter
setting
1 2 3 4 5 6 7
MODE
6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0000
OK
h
Res
▲
appears
1 2 3 4 5 6 7
MODE
5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0000
OK
h
Res
