Xylem YSI MultiLab 4010-1 Schnellstartanleitung Seite 5

MultiLab 4010(P)-1W
Display (example: pH measurement)
3
2
1
Jack field /connections
Initial
commissioning
ba76149y04
Downloaded from www.Manualslib.com
AutoCal TEC
HOLD AR
01.07.2011
Info USB output
08:00
1
1 Insert the supplied batteries.
Make sure that the poles are in the correct position.
2 Connect the power pack if necessary.
3 Switch on the meter with the <On/Off> key.
Caution
Follow the safety instructions of the used sensors.
The operating manuals of the sensors are available on the supplied CD and on
the Internet under www.YSI.com.
03/2018
manuals search engine
1
4
2
3
4
5
5
6
6
7
7
1
2
3
4
5
2 3 4
5
Status information
Measured value (with unit)
Measured parameter
Continuous measurement control
(CMC function)
Sensor symbol
(calibration evaluation)
Measured temperature (with unit)
Softkeys and date/time
IDS sensors
(pH, conductivity, D.O.)
USB B interface (device)
ProOBOD
Connection for line adaptor
Service interface
EN
English
5
