Presettingservos
X
X
ADVICE:Iftheservodoesnotmoveafterthenextstep,thismeansthatpolar-
ityisreversedattheconnector.Insuchacasesimplyrotatetheplugby180°.
X
X
X
EN
X
X
X
X
40
Downloaded from
www.Manualslib.com
Pressthe»+«key.
Theanalogprogrammingpathisactivated.
»Servo1«LEDlightsup.
Usingthe»+«and»-«keys,selecttheportoftheservothatyouwant
topreset.
Pressthe»Enter«key.
Theservoconnectedtotheselectedportbrieflymoves.
Usingthe»+«and»-«keys,presetthefirstholdpositionoftheservo
(holdposition"red").Bykeepingthekeyspressed,youwillalsobeable
toperformlargechangesofpositioneasily.
Pressthe»Enter«key.
Theservomovestothesecondholdposition.
Usingthe»+«and»-«keys,presetthesecondholdpositionoftheservo
(holdposition"green").Bykeepingthekeyspressed,youwillalsobe
abletoperformlargechangesofpositioneasily.
Pressthe»Enter«key.
Theservomovestoandfrobetweenbothpresetholdpositions.
Usingthe»+«and»-«keys,presetthemotionrateoftheservo.
Pressthe»Enter«key.
Thesettingsaresaved.
TheLEDoftheprogrammedservoportgoesout.
»Prog«LEDflashesatlowerheartrate.
