Unite TP – Bodypack Transmitter
4.2.1 How to configure a "Sub-Master"
In order to configure the Unite TP transmitter as a "Sub-
Master", proceed as described below:
• Use the On/Off and menu button
menu
"System" g "Device Mode".
• Select the "Sub-Master" option.
• Confirm the selected option with the On/Off and menu
button .
• Restart the transmitter by pressing the On/Off and
menu button
• The transmitter reconfigures itself. This can take
1 - 2 minutes.
• You can reconfigure the device as "Master" at any
time.
4.2.2 How to connect a "Sub-Master" to a "Master"
In order to connect a "Sub-Master" to a "Master", you
have to perform a channel search. Please proceed as
described below:
• Press the p or q symbol of the multifunction button
and start the dynamic channel search.
• The basic conditions to establish a connection must
be guaranteed (refer to chapter "Pairing information").
Alternatively, you can transmit the pairing information
via a charger. As a "Sub-Master", the transmitter will
receive the channel name, group ID and audio
encryption key from the charger like a Unite RP or RP-T.
.
to access the
21
