temporary uninterrupted operation of your equipment during a power failure. (DO NOT plug a laser
printer, paper shredder, copier, space heater, vacuum, sump pump or other large electrical devices
into the "Battery and Surge Protected Outlets". The power demands of these devices may overload
and damage the unit.)
8. Serial / USB Ports to PC
The Serial and USB ports allow connection and communication between the computer and the
UPS unit. Note: Only one port can be used at a time.
9. EPO Port
Use the provided gray EPO cable to connect to a provided EPO contact switch. Follow the
appropriate circuit diagram to the right to wire the cable to your EPO configuration. The EPO
remote switch is a switch installed in an outside area, connected to the unit via the Emergency
Power Off cable. In case of an emergency, it can be used to immediately cut-off power from the
UPS.
10. SNMP/HTTP Network Slot
Remove the cover panel to install an optional RMCARD to remotely monitor and manage your UPS
over a network.
11. Extended Battery Module Connecter (Except for PR2200ELCDSL/PR3000ELCDSL)
Use to connect optional CyberPower external battery pack (BP48VPT01) for extended runtime.
12. Circuit Breaker
Located on the back of the UPS, the circuit breaker provides overload and fault protection.
13. AC Input
Connect the AC power cord to a properly wired and grounded outlet.
1. Your new UPS may be used immediately upon receipt. However, recharging the battery for at
least 8 hours is recommended to ensure that the battery's maximum charge capacity is achieved.
Charge loss may occur during shipping and storage. To recharge the battery, simply leave the unit
plugged into an AC outlet. The unit will charge in both the on and off position.
Note: This UPS is designed with a safety feature to keep the system from being turned on
during shipment. The first time you turn the UPS on, you will need to have it connected to
AC power or it will not power up.
2. If you will use the software, connect the USB cable to the USB port on the UPS.
3. With the UPS unit off and unplugged, connect the computer, monitor, and any externally powered
data storage device (Zip drive, Jazz drive, Tape drive, etc. into the battery power supplied outlets.
DO NOT plug a laser printer, copier, space heater, vacuum, paper shredder or other large
electrical device into the battery power supplied outlets. The power demands of these devices will
