Type:
Entlüftungsstation / venting stationC 7030
Date:
14-SEP-2011
XXXXXXX
XXXXXXXXXXXXXXXXXXXX
Pos
Item No
Bezeichnung
2 7072400
GASWASCHFLASCHE
3 7052800
GL-VERSCHRAUBUNG
4 7229000
DRUCKSCHLAUCH
5 0736700
SCHLIFFKLEMME RV 05.11
7 3027400
GRUNDPLATTE
9 7225900
GUMMIPLATTE
10 0342700
GUMMIFUSS
11 7229100
ABLASSCHLAUCH
14
KLEBER
15 3013500
FRONTSCHILD
20 3014000
ENTLUEFTUNGS-ADAPTER
22 1583400
O-RING
23 7163700
O-RING
24 3013900
RAENDELSCHRAUBE
30
LEISTUNGSSCHILD C7030
40 7182700
RING
41 7182800
AUFNAHMETELLER
42 7183000
TELLERFEDER
43 7183100
DISTANZSTUECK
44 7182500
ENTLUEFTUNGSKOPF
45 1583700
O-RING
46 7227000
DROSSELSCHRAUBE bearb.
47 7226800
RAENDELMUTTER
48 7178900
VERSCHRAUBUNG GERADE
49 1740300
O-RING FPM V80G
80 1609400
SENKSCHRAUBE
81 1437400
SENKSCHRAUBE
2951000
EINMAULSCHLÜSSEL
2564900
DOPPELMAULSCHLÜSSEL
90 2746600
WARNSCHILD
®
IKA
Service-Manual
XXXXXXXXXXXXXXXXXXXX
Description
Technical data
WASH BOTTLE
GL SCREW FITTING
GL14
PRESSURE HOSE
CLIP RV 05.11
Kunststoff / plastic
BASE PLATE
RUBBER PLATE
D= 84,0
RUBBER FOOT
D 12,0x 3,6
DRAIN HOSE
ADHESIVE
Loctite 638
FACE PLATE
C7030
AIR VENT.ADAPTOR
O-RING
8,00x 2,50
O-RING
5,00x 2,00
KNURLED SCREW
POWER PLATE
RING
PLATE
DISK SPRING
DISTANCE
VENT CONNECTION
O-RING
5,00x 1,50
TROTTLE SCREW
KNURLED NUT
M 5,0
THREADED JOINT
VA 4-M5
O-RING FPM V80G
2,00x 1,60
COUNTERSUNK HEAD SCREW
M 4,0x12,0 4.8-A
COUNTERSUNK HEAD SCREW
M 4,0x20,0 4.8-A
SINGLE-HEAD WRENCH
SW 10
DOUBLE-HEAD WRENCH
SW 8 x 10
DANGER SIGN
SL 12,5
Bemerkung
Item No.:3013300
SZ: 3013300_d
Remark
1 / 1
