square and press down. The display shows a plus sign,
along with the location for that square. To add another
piece of the same type, simply press down on another
square. To add a different piece, press a different Piece
Symbol Key and follow the same steps as above.
• To clear the board, press YES/? ? ? ? ? while you are in
Position Mode. The display will show _ to symbolize
an empty chessboard, and the computer will ask Clear
board? Press YES/? ? ? ? ? once more to confirm that you do
want to clear the board. Then add pieces as described
previously. If you do not want to clear the board, press
NO/X to cancel. This feature can be handy when you
want to set up a position with only a few pieces, where it
would be easier to start out with an empty board!
• Once you have changed the position as described
above, make sure the color indicator in the display is
showing the correct color of the side to move. Change
the color, if necessary, by pressing BLACK or WHITE.
• To exit Position Mode, press NO/X. When the computer
asks for confirmation with End?, press YES/? ? ? ? ? to return
to normal play with your new board position.
Note that any legal board position can be set up using the
above procedures. The computer will not permit you to set up
an illegal position, such as one where there are more than
the prescribed number of pieces for a normal game, or one
where a King is in check and is not to move. In such cases,
after you press NO/X to exit Position Mode, and then YES/ ? ? ? ? ?
to confirm, the computer will display Error . You will not be
allowed to exit Position Mode until you have set up a legal
board position.
8. TECHNICAL DETAILS
8.1 The ACL Function
Computers sometimes "lock up" due to static discharge or
other electrical disturbances. If this should happen, take out
the batteries and use a pin or another sharp object to press
into the hole marked ACL in the base of the unit for at least
one second. This resets the computer.
8.2 Care and Maintenance
Your chess computer is a precision electronic device, and
should not be subjected to rough handling or exposed to
extreme temperatures or moisture. Be sure to disconnect the
adapter (if applicable) and remove the batteries before
cleaning this unit. Do not use chemical agents or liquids to
clean the unit, as they may damage the plastic.
Weak batteries should be replaced promptly, since they
can leak and damage the computer. Please also note the
following regarding the use of batteries. Warning: Use only
alkaline or zinc carbon batteries. Do not mix different
types of batteries or new and used batteries. Do not
recharge non-rechargeable batteries. Use only the rec-
ommended batteries or equivalent. Be sure to observe
the correct polarity when inserting batteries. Worn out
batteries should be removed from the unit promptly. Do
not short circuit the supply terminals.
If an AC-DC adapter is used with this unit, it must be as
specified in Section 8.3. An adapter is not a toy and should
Downloaded from
www.Manualslib.com
manuals search engine
TRY OUT POSITION MODE!
1. Press NO/X and YES/? together to
reset the computer for a new game.
NO/
YES/
Display: 0:00:00.
2. Press POSITION to enter Position
Mode. Display: -POS-.
POSITION
3. Press the White pawn down on
Square e2, and remove it from the
board. Display: [!-E2.
e2
4. Press that same pawn down on
Square e3 to add it to the board.
e3
Display: [!+E3.
5. Press the Black Queen down on
Square d8, and remove it from the
d8
board. Display: ]%-D8.
6. Press that same Queen down on
Square h5 to add it to the board.
Display: ]%+H5.
h5
7. Press WHITE to change the color to
WHITE
move next.
8. Press NO/X to exit; then press YES/?
to confirm your new position and
NO/
return to game play.
YES/
For more details, see Section 7.2.
be handled with care. Please also note the following regard-
ing the use of an AC-DC adapter. Warning: Use a center
positive adapter with safety isolating transformer. The
polarity symbols confirming its center positivity should
be clearly marked on the adapter, and the adapter must
comply with CEE publication 15. The adapter should be
regularly examined for potential hazards such as dam-
age to the plug, cable or cord, casing or other parts. In
the event of damage, the adapter should not be used.
8.3 Technical Specifications
Keys:
17
LED Lamps:
64; 3 mm
LCD Display:
48-segment, 5-digit
Speaker:
78 mm diameter
Batteries:
6 x (1.5V) "C" (AM2/R14) cells
Dimensions:
410 x 270 x 40 mm
Weight:
1.3 Kg
AC-DC Adapter:
9V/300mA center-positive
(EN 60742 compliant)
Please retain this information for future reference.
Saitek reserves the right to make technical changes without notice in the
interest of progress.
15
