CPU_FAN
SYS_FAN
LDC
LPC signal
Power +3.3V
1
LPC Signal
LPC Signal
CASE
Intruder
ME_UNLOCK
UNLOCK
LOCK
CLR_CMOS Jumper
1-2: NORMAL
2-3: CLEAR CMOS
1 2
3
Before clearing the CMOS, make sure to turn off the system.
CLR_CMOS
H81H3-MV USER MANUAL
System Ground
Power +12V
Sensor
PWM
System Ground
Power +12V
Sensor
PWM
Reset
Clock
Key
Ground
LPC Signal
LPC Signal
GND
5
