Disclaimer
The information in this document is subject to change without notice. The
manufacturer makes no representations or warranties with respect to the contents
hereof and specifically disclaims any implied warranties of merchantability or
fitness for any particular purpose. The manufacturer reserves the right to revise this
publication and to make changes from time to time in the content hereof without
obligation of the manufacturer to notify any person of such revision or changes.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits
governing this device. Changes or modifications not expressly approved by the
system's manufacturer could void the user's authority to operate the equipment.
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the follow-
ing conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
This device is in conformity with the following EC/EMC directives:
Limits and methods of mesurement of radio disturbance char-
EN 55022
acteristics of information technology equipment
EN 61000-3-2
Disturbances in supply systems caused
Disturbances in supply systems caused by household appli-
EN 61000-3-3
ances and similar electrical equipment " Voltage fluctuations"
EN 55024
Information technology equipment-Immunity characteristics-
Limits and methods of measurement
EN 60950
Safety for information technology equipment including electri-
cal business equipment
CE marking
H110M4-C43(C33)/B150M4-C43 USER MANUAL
®

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für ECS H110M4-C43

  • Seite 1 Disturbances in supply systems caused by household appli- EN 61000-3-3 ances and similar electrical equipment “ Voltage fluctuations” EN 55024 Information technology equipment-Immunity characteristics- Limits and methods of measurement EN 60950 Safety for information technology equipment including electri- cal business equipment CE marking H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 2: Inhaltsverzeichnis

    TABLE OF CONTENTS Preface Brief Introduction Specifications..................1 Motherboard Components..............3 Header Pin Definition and Jumper Settings.........5 I/O Ports....................8 Multi-language Quick Installation Guide English....................9 Brazilian Portuguese.................11 Hindi........................13 French......................15 Deutsch....................17 Russian....................19 Spanish....................21 Indonesian.....................23 Arabic.......................25 Simplified Chinese................27 Korean......................29 H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 3: Brief Introduction

    Brief Introduction Specifications ® • LGA1151 socket for Intel Skylake processor • Supports CPU up to 95W Note: Please go to ECS website for the latest CPU support list. ® Chipset • Intel H110/B150 Chipset Memory • Dual-channel DDR4 memory architecture •...
  • Seite 4 Micro ATX Size, 244mm x 210mm Please take the actual motherboard as standard. H110M4-C33 does not have M.2 slot. Only B150M4-C43 has five SATA connectors, H110M4-C43 has three SATA connectors, and H110M4-C33 has four SATA connectors. QR Code for the complete manual download on ECS website: http://www.ecs.com.tw...
  • Seite 5: Motherboard Components

    Motherboard Components H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 6 4-pin system cooling fan connector 23. ATX_12V 4-pin +12V power connector Please take the actual motherboard as standard. Only B150M4-C43 has five SATA connectors, H110M4-C43 has three SATA connectors, and H110M4-C33 has four SATA connectors. H110M4-C33 does not have M.2 slot. H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 7: Header Pin Definition And Jumper Settings

    Front Panel USB Power USB3 ICC Port2 D+ Front Panel USB Power USB3 ICC Port2 D- USB3 ICC Port2 SuperSpeed Rx- Ground USB3 ICC Port2 SuperSpeed Rx+ USB3 ICC Port2 SuperSpeed Tx+ Ground USB3 ICC Port2 SuperSpeed Tx- H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 8 LPCPD# TPM_CLK SMBCLK SERIRQ SMBDATA RESERVE1 LAD2 LAD1 Ground Ground Ground Ground SLCT Ground INIT Ground ERROR Ground Ground STROBE SLCT BUSY CPU_FAN System Ground Power +12V Sensor SYS_FAN System Ground Power +12V Sensor Signal Power +5V H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 9 CASE Chassis cover Chassis cover is removed is closed ME_DIS Disable Enable CLR_CMOS Jumper 1-2: NORMAL 2-3: CLEAR CMOS Before clearing the CMOS, make sure to turn off the system. CLR_CMOS H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 10: I/O Ports

    It can be connected to an external CD/DVD player, Tape player or other audio devices for audio input. 11. Line-out (lime) It is used to connect to speakers or headphones. 12. Microphone (pink) It is used to connect to a microphone. H110M4-C43(C33)/B150M4-C43 USER MANUAL...
  • Seite 11: Multi-Language Quick Installation Guide

    Hardware Installation Guide Installation Steps Step 1. Installation of the CPU and CPU Cooler: 1-1. Pull up the lever away from the 1-2. Rotate and press down the fastener socket. Align the CPU cut edge with the of CPU fan to the motherboard through indented edge of the CPU socket.
  • Seite 12 Step 5. Connecting Cables and Power Connectors: a. Connect the SATA hard drive to its b. Connect SATA power connector to the SATA cable SATA device c. Connect 24-pin power cable d. Connect 4-pin power cable Please note that when installing 24-pin The ATX_12V 4-Pin power connector is used power cable, the latches of power cable to provide power to the CPU.
  • Seite 13: Brazilian Portuguese

    Manual de Instalação de Hardware Etapas para instalação Passo 1. Instalação da CPU e da CPU Refrigeração (Cooler): 1-1. Puxe a alavanca para fora do 1-2. Gire e pressione para baixo a soquete. Alinhe o lado da CPU com o alavanca de fecho da ventoinha da CPU lado correto do soquete do processador.
  • Seite 14 Passo 5. Conexão de cabos e conectores de alimentação: a. Conecte o disco rígido SATA ao seu b. Ligue o conector de alimentação SATA ao cabo SATA. c. Ligue o cabo de alimentação 24 pinos. d. Ligue o cabo de alimentação de 4-pinos. Por favor note que ao instalar o cabo de O conector de alimentação ATX_12V de 4-Pin alimentação de 24 pinos, as travas do...
  • Seite 15: Hindi

    1-1. 1-2. CPU 2-1. DIMM 2-2. DIMM 3-1. 3-2.
  • Seite 16 SATA SATA SATA SATA ATX_12V 4- ATX_12V BIOS ( BIOS (POST) <DEL> POST DK^ ^ CMOS BIOS >...
  • Seite 17: French

    1-1. Ecartez le levier du socket. Alignez 1-2. Tournez et appuyez sur la le bord coupé du CPU avec le bord correspondant sur le socket du CPU. carte mère à travers les trous pour Placez soigneusement le CPU dans la bonne de pâte thermique sur la surface du CPU.
  • Seite 18 a. Connectez le disque dur SATA à son câble SATA au périphérique SATA broches broches connecteur ATX correspondent connecteur ATX_12V. parfaitement. Une fois que les étapes ci-dessus ont été e ectuées, connectez les périphériques tels que le clavier, la et allumez le système.
  • Seite 19: Deutsch

    1-2. Lösen Sie durch eine Drehung die Pushpins 1-1. Lösen Sie den Hebel vom des CPU-Kühlers und richten Sie diese mit den CPU-Sockel. entsprechenden Löchern Kunststo abdeckung und richten Sie die aus und drücken Sie die Kerbe der CPU mit der entsprechenden Pushpins nach unten bis sie einrasten.
  • Seite 20 b. Schließen Sie die SATA-Stromanschlusskabel a. Schließen Sie das/die SATA-Kabel der an den SATA-Geräten an c. Stecken Sie das 24-Pin-Stromversorgungskabel d. Stecken Sie das 4-Pin-Stromversorgungsk in den entsprechenden Anschluss auf der abel in den entsprechenden Anschluss auf Der ATX_12V 4-Pin-Anschluss versorgt die CPU mit der einen Seite des 24-Pin- Stromversorgungskabels am ATX-Anschluss der einen Seite des 4-Pin-Stromversorgungska...
  • Seite 21: Russian

    1-1. 1-2. /DD /DD /DD 3-1. 3-2.
  • Seite 22 SATA SATA SATA SATA ATX_12V. ATX_12V. BIOS BIOS ( BIOS POST ( <DEL > CMOS). BIOS “Load Default CMOS...
  • Seite 23: Spanish

    Guía de instalación del hardware Pasos para realizar la instalación Paso 1. Instalación de la CPU y sistema de refrigeración de la CPU: 1-2. Gire y presione hacia abajo la sujeción 1-1. Tire de la palanca hacia arriba, apartándola del zócalo. Alinee el base borde recortado de la CPU con el a través de los ori cios, para instalar...
  • Seite 24 Paso 5. Conexión de los cables y los conectores de alimentación: a. Conecte el disco duro SATA al cable b. Conecte el conector de alimentación SATA SATA. c. Conecte el cable de alimentación de 24 d. Conecte el cable de alimentación de 4 pines.
  • Seite 25: Indonesian

    Panduan Pemasangan Perangkat Keras Langkah-Langkah Pemasangan Langkah 1. Pemasangan CPU dan Pendingin CPU: 1-1. Tarik tuas dari soket. Luruskan 1-2. Putar dan tekan penahan kipas CPU tepi pemisah CPU dengan tepi ke lubang tembus motherboard untuk bertakik dari soket CPU. Pasang CPU memasang kipas CPU pada tempatnya.
  • Seite 26 Langkah 5. Menyambungkan Kabel dan Konektor Daya: a. Sambungkan hard drive SATA ke kabel b. Sambungkan konektor daya SATA ke SATA perangkat SATA c. Sambungkan kabel daya 24 pin d. Sambungkan kabel daya 4 pin Konektor daya ATX_12V 4 pin digunakan untuk kabel daya 24, kait pada kabel daya menyediakan daya ke CPU.
  • Seite 27: Arabic

    ‫دﻟﻴﻞ ﺗﺮﻛﻴﺐ اﳌﻜﻮﻧﺎت اﻟﺼﻠﺒﺔ‬ ‫ﺧﻄﻮات اﻟﱰﻛﻴﺐ‬ :‫اﻟﺨﻄﻮة رﻗﻢ 1. ﺗﺮﻛﻴﺐ وﺣﺪة اﳌﻌﺎﻟﺠﺔ اﳌﺮﻛﺰﻳﺔ وﻣﱪد وﺣﺪة اﳌﻌﺎﻟﺠﺔ اﳌﺮﻛﺰﻳﺔ‬ ‫1-2 ﻗﻢ ﺑﺎﻹدارة واﻟﻀﻐﻂ ﻷﺳﻔﻞ ﻋﲆ ﻣﺸﺒﻚ ﻣﺮوﺣﺔ وﺣﺪة اﳌﻌﺎﻟﺠﺔ‬ ‫اﳌﺮﻛﺰﻳﺔ ﰲ اﻟﻠﻮﺣﺔ اﻷم ﻋﱪ اﻟﻔﺘﺤﺎت ﻟﺘﺜﺒﻴﺖ ﻣﺮوﺣﺔ وﺣﺪة اﳌﻌﺎﻟﺠﺔ‬ ‫وﺣﺪة اﳌﻌﺎﻟﺠﺔ اﳌﺮﻛﺰﻳﺔ ﻣﻊ اﻟﻄﺮف اﳌﺴﻨﻦ ﳌﻘﺒﺲ وﺣﺪة اﳌﻌﺎﻟﺠﺔ‬ .‫اﳌﺮﻛﺰﻳﺔ...
  • Seite 28 :‫اﻟﺨﻄﻮة رﻗﻢ 5. ﻛﺒﻼت اﻟﺘﻮﺻﻴﻞ وﻣﻮﺻﻼت اﻟﻄﺎﻗﺔ‬ ‫ ﺑﺎﻟﺠﻬﺎز ﻣﻦ ﻃ ﺮ از‬SATA ‫ب. ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﻣﻮﺻﻞ اﻟﻄﺎﻗﺔ ﻣﻦ ﻃ ﺮ از‬ ‫ اﻟﺨﺎص ﺑﻪ‬SATA ‫ ﺑﻜﺒﻞ‬SATA ‫أ. ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﻣﺤﺮك اﻷﻗ ﺮ اص ﻣﻦ ﻃ ﺮ از‬ SATA ‫د. ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﻛﺒﻞ اﻟﻄﺎﻗﺔ اﳌﺰود ﺑﻌﺪد 4 دﺑﻮس‬ 0‫ج.
  • Seite 29: Simplified Chinese

    硬件安装指南 安装步骤 1.安装CPU和CPU风扇: 1-2. 将CPU风扇扣具对齐主板上的对应 1-1. 松 开 C P U 插 槽 旁 的 固 定 杆 , 向 孔位,向下按压并且旋转扣具 ,固 定 上 拉 固 定 杆 , 并 掀 开 插 槽 上 的 保 护 盖 。 CPU风扇。...
  • Seite 30 5.连接电源线与电源接头: a. 将SATA电缆连接至SATA 硬盘 b. 将SATA电源接头连接至SATA设备 c. 连接24针电源线与电源接头 d. 连接4针电源线与电源接头 请注意电源接头与电源线必须完全扣合。 4针电源接头提供CPU电源。其电源接头与电 源线必须完全扣合。 6.连接机箱端口: 当上述安装步骤完成后,请开始安装键盘,鼠标, 显示器等外围设备,然后连接电 源并启 动系统。请安装好所需的软件。 BIOS使用设定 BIOS程序画面会显示系统配置,同时提供操作选项让您设定系统参数。当开机时, BIOS会进行开机自我测试 (POST),请点击 <D EL> 或 F2 进入BIOS程序设定。第一次 开机时,POST画面可能会显示 信息,请进入BIOS选单 并选 择 将BIOS重新设定为默认值 (更换CPU或内存等硬件变更也 可能会出现此信息)。 此说明内容中提供图片或安装方式仅供参考。...
  • Seite 31: Korean

    하드웨어 설치 가이드 단계별 설치 방법 쿨러 설치하기: 1단계. CPU와 CPU 1-1. 소켓에서 레버를 뽑아 냅니다. 1-2. 패스너를 돌려 CPU 팬을 마더보 드 의 쓰루-홀에 눌러 넣어 CPU 팬을 제 위치 끝 부분을 CPU 소켓의 들어간 끝 부분에 에 설치합니다. 맞춥니다.
  • Seite 32 5단계. 케이블 및 전원 커넥터 연결하기: a. SATA 하드 드라이브를 SATA b. SATA 전원 커넥터를 SATA 장치에 연결합 케이블에 연결합니다 니다 c. 4핀 전원 케이블을 연결합니다 d. 4핀 전원 케이블을 연결합니다 24핀 전원 케이블 연결시 전원 케이블과 ATX_12V 4핀 전원 커넥터는 전원을 CPU에 ATX 커넥터의...

Diese Anleitung auch für:

H110m4-c33B150m4-c43
