E+E Elektronik EE300Ex Serie Bedienungsanleitung Seite 41

EE300EX-M3A6HS2aD1bcdeEX3f
a = Model; T24
b = Electrical Connection; E2, E13, E15, E17, E18, E19, E20, E21, E22 or E32
c = Probe – Cable Length; K0.2, K0.5, K1, K2, K3, K5 or K10
d = Probe length; L150
e = Zone Feedthrough (probe fitting): PA0, PA26 or PA27
f = Software Code: 7 to 10 Digits (Not Safety Relevant)
Entity parameters:
Terminals
CH 1: + and - 6.4Vdc ≤ Ui ≤28Vdc
CH 2: + and - 6.4Vdc ≤ Ui ≤28Vdc
Remote probe - Temperature Code:
T-Code Ambient Temperature
T6 -70°C < Ta < 60°C
T5 -70°C < Ta < 75°C
T4 -70°C < Ta < 110°C
T3 -70°C < Ta < 175°C
T2 -70°C < Ta < 200°C
T1 -70°C < Ta < 200°C
13. Specific Conditions of Use:
Equipment Group I: EE300Ex without display
1. Filter options F2, F5, F10, F11 and F12 are not allowed in Groups A or B for Division 1 and EPL Ga IIC for
Zone 0.
2. The EE300Ex Remote Probe is approved for in air applications only.
3. The serial software configuration port of the EE300EX may only be used with the Product Configuration
Adapter (PCA) and Connection cable (HA011068).
Equipment Group II: EE300Ex with display
1. The EE300Ex Remote Probe is approved for in air applications only.
2. The serial software configuration port of the EE300EX may only be used with the Product Configuration
Adapter (PCA) and Connection cable (HA011068).
14. Test and Assessment Procedure and Conditions:
This Certificate has been issued in accordance with FM Approvals US Certification Requirements.
15. Schedule Drawings
A copy of the technical documentation has been kept by FM Approvals.
THIS CERTIFICATE MAY ONLY BE REPRODUCED IN ITS ENTIRETY AND WITHOUT CHANGE
FM Approvals LLC. 1151 Boston-Providence Turnpike, Norwood, MA 02062 USA
T: +1 (1) 781 762 4300 F: +1 (1) 781 762 9375 E-mail:
F 347 (Mar 16)
Bedienungsanleitung EE300Ex Feuchte / Temperatur Sensor
SCHEDULE
US Certificate Of Conformity No: FM17US0302X
Vmax or Ui Imax or Ii Pi
100mA
100mA
information@fmapprovals.com www.fmapprovals.com
Li Ci
0.7W 0mH 2.2nF
0.7W 0mH 2.2nF
Page 6 of 7
