active fun TP340 Anweisungen Für Die Montage, Wartung Und Den Gebrauch Seite 8

TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 8
FA4513
4.5mm x 30mm Woodscrew
FA4515
4.5mm x 55mm Woodscrew
FA4521
5mm x 80mm Woodscrew
FA8442
5mm x 40mm Woodscrew
FA8380
M8 x 40mm Coach screw
FA8443
Nº12 × 63mm (2½")
FA5688
M8 x 70mm Bolt
FA9784
M6 x 150mm Woodscrew
Bolt Tightening Guide
x45
(25mm o/dia)
x74
x7
x117
x3
FA9724
M5 x 25mm Bolt
x2
x8
x2
Fixings - SP 8500
FA7184 FA9723
M8 Washer M5 Washer
x6
x33
FA5094
M6 Washer
x1
FA5170
x6 M6 x 70mm Bolt
FA9701
x8
M8 x 100mm Bolt
8
FA5192
FA4508
M6 Nylon Insert
M5 Nylon Insert
Dome Nut
Dome Nut
x1
x6
FA8163
PM8293
M8 Nylon Insert
10mm Plug
x2
Dome Nut
x16
PM8294
12mm Plug
x20
x1
TP Castlewood Tower
