TP795
Forest Villa
INSTRUCTIONS FOR ASSEMBLY
MAINTENANCE AND USE
Important!
These instructions must be followed for safe assembly and use.
Please retain for future reference.
Important!
Vous devez suivre ces instructions pour que le montage et l'utilisation se
fassent en toute sécurité. Veuillez conserver pour référence ultérieure.
Importante!
Per garantire sicurezza di montaggio ed uso, seguire queste istruzioni e
conservarle per futuro riferimento.
Importante!
Debe seguirse estas instrucciones para un armado y uso seguros.
Sírvase conservarlas para consultarlas en el futuro.
Wichtig!
Diese Anweisung ist für sicheren Aufbau und Gebrauch zu befolgen.
Für künftigen Gebrauch aufbewahren.
Importante!
Para assegurar uma montagem e uma utilização seguras, têm de ser
seguidas estas instruções. Guardar para referência futura.
WARNING
TOY MUST BE ASSEMBLED BY
AN ADULT BEFORE USE.
Children must not use the
equipment until properly installed.
Assembly Build
WARNING only for domestic use
Outdoor use
Important!
Age 3-8 yrs

Werbung

loading

Inhaltszusammenfassung für active fun TP795

  • Seite 1 TP795 Forest Villa INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE WARNING Important! These instructions must be followed for safe assembly and use. Please retain for future reference. TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE. Important! Vous devez suivre ces instructions pour que le montage et l’utilisation se fassent en toute sécurité.
  • Seite 2 6 languages 3-8yrs En71 05 13:6 languages 3-8yrs En71 11 12 13/05/2013 11:18 Page 1 INSTRUCTIONS FOR ASSEMBLY, MAINTENANCE AND USE OF TP TOYS - Please read carefully and keep all enclosed information for future reference. 1. ASSEMBLY TP toys must be assembled by an adult. They must be erected exactly in accordance with the assembly instructions. Enlisting the aid of a helper will make AND SAFETY assembly easier.
  • Seite 3 6 languages 3-8yrs En71 05 13:6 languages 3-8yrs En71 11 12 13/05/2013 11:18 Page 2 INSTRUCCIONES DE MONTAJE, MANTENIMIENTO Y USO DE LOS JUGUETES TP Lea detenidamente toda la información adjunta y consérvela para futuras consultas. 1. INFORMACIÓN Los juguetes TP deben ser montados por un adulto. Deben armarse siguiendo fielmente las instrucciones de montaje, y será más fácil hacerlo con la SOBRE MONTAJE ayuda de otro adulto.
  • Seite 4 Instruction Guide Read Instructions Before Starting Hidden Lines Sort Fixings Sort Parts Need Help? Visit: www.tptoys.com TP Customer Services (English Speaking) 100 110 120 130 140 150 Forest Villa...
  • Seite 5 Tools - You will need: Contents - Please check Siete Pregati di Controllare il Contenuto Vous aurez besoin de: Pozi #2 Power Screwdriver Sie benötigen: Verifique El Contenido Conteúdos - Por favor verifique Pozi #3 Tape Measure Avrete bisngo: Inhalt - Bitte Überprüfen Contenu - Veuillez Vérifier 3mm Drill Bit Precisará:...
  • Seite 6 SP7945 - Box 1 of 3 Fixings FA4516 FA4513 FA9761 PM2038 4.5x15 4.5x30 5x100 x110 795 - Box 2 of 4 Parts MW2545 MW2547 MW2549 MW2552 1223mm 1101mm 376mm 1544mm MW2554 MW2555 MW2556 MW2557 MW2558 1907mm 763mm 298mm 589mm 285mm TP346 MW2561 Universal Sandpit Cover...
  • Seite 7 795 - Box 3 of 4 Parts Cont. MW2540 MW2541 MW2551 1189mm 1179mm 1100mm MW2553 MW2559 MW2560 1189mm 1059mm 298mm PR8971 FB9985 PM2001 TP Badge Sandpit Liner Ground Peg SP7951 - Box 3 of 4 Fixings 795 - Box 4 of 4 Parts FA4513 FA4517 FA9705...
  • Seite 8 Pack 1 of 3: House MW2530 MW2531 MW2534 FA9761 MW2517 1149mm 1149mm 623mm 5x100 891mm MW2531 MW2534 MW2534 MW2517 MW2517 MW2530 MW2534 MW2534 FA4513 MW2516 891mm 4.5x30 Forest Villa...
  • Seite 9 MW2516 MW2517 MW2531 MW2533 MW2535 FA4513 FA9761 891mm 891mm 1149mm 81mm 672mm 4.5x30 5x100 MW2550 891mm 4.5x30mm MW2531 5x100mm MW2517 5x100mm 4.5x30mm MW2517 MW2550 4.5x30mm MW2516 MW2535 5x100mm 4.5x30mm MW2533 5x100mm Forest Villa...
  • Seite 10 MW2520 FA4513 1116mm 4.5x30 Forest Villa...
  • Seite 11 MW2536 FA4513 693mm 4.5x30 Note: Undo and re-use 5x100mm screw used in stages 1 and 3. Forest Villa...
  • Seite 12 MW2516 891mm FA4513 4.5x30 Space boards evenly. MW2516 891mm FA4513 4.5x30 Forest Villa...
  • Seite 13 MW2521 195mm MW2522 394mm FA4513 4.5x30 PM2040 FA4516 4.5x15 PM2038 Forest Villa...
  • Seite 14 MW2518 MW2519 MW2520 MW2523 MW2524 FA4513 928mm 981mm 1116mm 1076mm 1030mm 4.5x30 Space boards evenly. Forest Villa...
  • Seite 15 MW2522 394mm MW2524 1030mm FA4513 4.5x30 Space boards evenly. MW2525 MW2529 232mm 380mm MW2526 MW2528 285mm 334mm MW2527 FA4513 380mm 4.5x30 Space boards evenly. Forest Villa...
  • Seite 16 FA4513 4.5x30 PM2040 FA4516 4.5x15 PM2038 Forest Villa...
  • Seite 17 MW2515 772mm FA4513 4.5x30 MW2515 772mm FA4513 4.5x30 Forest Villa...
  • Seite 18 Forest Villa...
  • Seite 19 Packs 2 and 3 of 4: Platform MW2540 MW2545 MW2553 FA9705 1189mm 1223mm 1189mm 4.5x50mm MW2553 MW2545 MW2553 MW2545 MW2545 MW2540 MW2545 MW2540 Forest Villa...
  • Seite 20 34.5mm Drill 3mm Pilot Holes MW2547 FA9784 1101mm M6x150mm 22mm Drill 3mm Pilot Holes 34.5mm MW2554 FA9784 1907mm M6x150mm Forest Villa...
  • Seite 21 MW2554 1907mm FA9784 M6x150mm 6X150mm MW2540 1189mm 4.5X40mm 6X150mm MW2555 763mm FA9784 M6x150mm FA4517 4.5x40mm Forest Villa...
  • Seite 22 MW2540 1189mm MW2541 1179mm FA9705 4.5x50mm Drill 3mm Pilot Holes MW0169 FA9794 295mm 4.5x50mm Forest Villa...
  • Seite 23 MW2551 MW2540 FA4517 1100mm 1189mm 4.5x40mm Line up hole Forest Villa...
  • Seite 24 MW2540 FA4517 1189mm 4.5x40mm Forest Villa...
  • Seite 25 MW2549 FA9784 376mm M6x150mm 34.5mm Drill 3mm Pilot Holes Forest Villa...
  • Seite 26 MW2552 FA9705 1544mm 4.5x50mm Forest Villa...
  • Seite 27 MW1501 MW0172 FA4517 FA9705 414mm 997mm 4.5x40mm 4.5x50mm 4.5x40mm 835mm 530mm 225mm 4.5x50mm Forest Villa...
  • Seite 28 MW2557 MW2558 FA9768 589mm 285mm 5x60mm MW2556 MW2560 FA9705 298mm 298mm 4.5x50mm Forest Villa...
  • Seite 29 FA9768 5x60mm MW2559 FA9705 1059mm 4.5x50mm Forest Villa...
  • Seite 30 MW2551 FA4513 1100mm 4.5x30 MW2561 FA4513 176mm 4.5x30 Forest Villa...
  • Seite 31 01 35 FA4521 5x80mm...
  • Seite 32 Pack 3 of 3: Slide FA9705 PV9595 4.5x50mm Slide Forest Villa...
  • Seite 33 01 36 PM2001 FA9768 Ground Peg 5x60mm Cement Ground pegs into position Forest Villa...
  • Seite 34 PR8971 TP Badge Forest Villa...
  • Seite 35 01 38 FB9985 Sandpit Liner Forest Villa...
  • Seite 36 Forest Villa...
  • Seite 37 Safe Play Area Forest Villa...
  • Seite 38 Register your new TP product on line now at www.tptoys.com/product registration Thank you for purchasing this TP product. To find out all about your product guarantee and register your purchase, please visit www.tptoys.com/productregistration We want to give you the very best service. By registering your purchase now, we will be able to deal with any guarantee issues very quickly and efficiently in the future.
