TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 1
TP340
TP Castlewood Tower
INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE
PLEASE RETAIN FOR FUTURE REFERENCE.
Important!
These instructions must be followed for safe assembly and use. Please retain for future reference.
Important!
Vous devez suivre ces instructions pour que le montage et l'utilisation se fassent en toute sécurité.
Veuillez conserver pour référence ultérieure.
Importante!
Per garantire sicurezza di montaggio ed uso, seguire queste istruzioni e conservarle per futuro riferimento.
Importante!
Debe seguirse estas instrucciones para un armado y uso seguros. Sírvase conservarlas para consultarlas en el futuro.
Wichtig!
Diese Anweisung ist für sicheren Aufbau und Gebrauch zu befolgen. Für künftigen Gebrauch aufbewahren.
Importante!
Para assegurar uma montagem e uma utilização seguras, têm de ser seguidas estas instruções. Guardar para referência futura.
WARNING!
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE. ADULT SUPERVISION IS REQUIRED.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 3 TO 12 YEARS.
MAXIMUM COMBINED USER WEIGHT 150KGS
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.
Assembly
Build

Werbung

loading

Verwandte Anleitungen für active fun TP340

Inhaltszusammenfassung für active fun TP340

  • Seite 1 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 1 TP340 TP Castlewood Tower INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE PLEASE RETAIN FOR FUTURE REFERENCE. Important! These instructions must be followed for safe assembly and use. Please retain for future reference.
  • Seite 2 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 2 INSTRUCTIONS FOR ASSEMBLY, MAINTENANCE AND USE OF TP TOYS - Please read carefully and keep all enclosed information for future reference.
  • Seite 3 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 3 INSTRUCCIONES DE MONTAJE, MANTENIMIENTO Y USO DE LOS JUGUETES TP Lea detenidamente toda la información adjunta y consérvela para futuras consultas.
  • Seite 4 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 4 Unlike steel, wood is a natural, organic material and each piece will be unique, bearing its own knots, cracks and variations in colour and, unlike steel, wood will react significantly to changes in atmospheric conditions.
  • Seite 5 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 5 Instruction Guide Read Instructions Before Starting Hidden Lines Sort Fixings Sort Parts Need Help? Visit www.tptoys.com TP Customer Services: (English Speaking)
  • Seite 6 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 6 Contents - Please check Tools - You will need: Vous aurez besoin de: Siete Pregati di Controllare il Contenuto Sie benötigen: Conteúdos - Por favor verifique...
  • Seite 7 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 7 Pack 3 FB9985 MW2050 Sandpit Liner PR5069 (589mm) MW0176 (413mm) MW2051 (589mm) PM1005 MW2034 (457mm) MW2041 (680mm) PM1007 MW2035 (586mm) MW2042...
  • Seite 8 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 8 Fixings - SP 8500 FA5192 FA4513 FA7184 FA9723 FA4508 M6 Nylon Insert 4.5mm x 30mm Woodscrew M8 Washer M5 Washer M5 Nylon Insert...
  • Seite 9 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 9 MW2037 FA4515 4.5mm x 55mm Woodscrew MW2018 (2237mm) MW2019 (2237mm) MW2020 (2237mm) MW2021 (2237mm) MW2022 (2237mm) 4.5mm x 55mm 10mm 10mm...
  • Seite 10 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 10 FA5688 FA9701 FA7184 FA8163 FA8442 MW2024 M8 Washer M8 x 70mm M8 x 100mm M8 Nylon Insert 5mm x 40mm (589mm)
  • Seite 11 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 11 FA9701 FA7184 FA8163 PM8293 MW2039 MW2024 M8 Washer M8 x 100mm M8 Nylon Insert 10mm Plug (579mm) (589mm) (25mm o/dia) Bolt...
  • Seite 12 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 12 MW2036 FA7184 FA5688 FA9701 FA8163 FA8442 MW2024 M8 Washer M8 x 70mm M8 x 100mm M8 Nylon 5mm x 40mm (589mm)
  • Seite 13 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 13 FA7184 FA5688 FA9701 FA8163 FA8442 MW2024 M8 Washer M8 x 70mm M8 x 100mm M8 Nylon Insert 5mm x 40mm (589mm)
  • Seite 14 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 14 FA7184 FA9701 FA8163 MW2024 M8 Washer M8 x 100mm M8 Nylon Insert (589mm) (25mm o/dia) Bolt Dome Nut MW2019 (2237mm) MW2022...
  • Seite 15 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:29 Page 15 FA7184 FA5688 FA9701 FA8163 FA8442 MW2036 M8 Washer M8 x 70mm M8 x 100mm M8 Nylon Insert 5mm x 40mm (589mm)
  • Seite 16 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 16 FA4515 MW2034 4.5mm x 55mm (457mm) Woodscrew 15mm 15mm ASSEMBLY TIP MW2026 as guide MW2025 (1104mm) FA9784 M6 x 150mm Woodscrew...
  • Seite 17 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 17 MW2026 MW2028 FA8442 (381mm) (974mm) 5mm x 40mm Woodscrew MW2027 (724mm) MW2019 Upright Check MW2019 Upright MW2029 (974mm) FA8442 5mm x 40mm...
  • Seite 18 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 18 MW2049 FA4515 32 mm (300mm) 4.5mm x 55mm 32mm Woodscrew 15mm 15mm ASSEMBLY TIP MW2026 as guide FA8442 MW2026 MW2027 5mm x 40mm...
  • Seite 19 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 19 MW2037 MW2037 MW2019 MW2019 Upright Upright Check 77mm 77mm 77mm 77mm 77mm 77mm 77mm MW2018 MW2018 MW2019 MW2019 Upright Upright Upright...
  • Seite 20 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 20 FA8442 5mm x 40mm MW2031 Woodscrew MW2023 (1024mm) MW2035 (650mm) (586mm) 174mm Check MW2031 850mm 80mm Check MW2035 MW2035 MW2023 650mm...
  • Seite 21 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 21 FA8442 MW0176 5mm x 40mm (413mm) Woodscrew MW2052 Check 235mm 235mm 235mm 180mm 255mm 220mm 50mm FA8443 Nº12 × 63mm (2½”)
  • Seite 22 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 22 FA4513 MW2047 4.5mm x 30mm MW2042 MW2044 (111mm) Woodscrew (585mm) (395mm) MW2046 (206mm) MW2043 (490mm) MW2045 MW2048 (301mm) MW2041 (680mm) (680mm)
  • Seite 23 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 23 FA4513 MW2040 4.5mm x 30mm (915mm) Woodscrew PM1005 PM1007 CLICK TP Castlewood Tower...
  • Seite 24 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 24 FA4521 5mm x 80mm Woodscrew 4.5mm x 80mm 83mm MW2057 FA4515 4.5mm x 55mm Woodscrew 3-5mm TP Castlewood Tower...
  • Seite 25 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 25 FA4508 FA9724 FA9723 M5 Nylon M5 x 25mm Bolt M5 Washer Insert Dome Nut x FA4513 ASSEMBLY TIP 4.5mm x 30mm...
  • Seite 26 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 26 FA5094 FA4513 PM1006 M6 Washer 4.5mm x 30mm Woodscrew FA5192 M6 Nylon FA5170 Insert Dome M6 x 70mm Bolt MT9127 Fireman’s Pole...
  • Seite 27 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 27 Slide Attachment Slide Attachment TP969 TP968 CrazyWavy Slide Wavy Slide Drill 3mm Pilot Holes TP Castlewood Tower...
  • Seite 28 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 28 Positioning / Freespace / Safe Play Diagram Recommended Free Space: The Safe Play Area refers to the zone extending 200cm (2 metres) beyond the toy on all sides and 700cm (7 metres) above the toy.
  • Seite 29 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 29 FB9985 Sandpit Liner Sand Not supplied FA8380 PR5069 M8 x 40mm Coach screw FA7184 M8 Washer (25mm o/dia) 50cm 35cm 35cm 45 °...
  • Seite 30 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 30 PM8294 12mm Plug TP Castlewood Tower...
  • Seite 31 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 31 TP Castlewood Tower...
  • Seite 32 TP340 Castlewood Tower IN3100 Issue F 10 13:TP340 Castlewood Tower IN3100 Issue F 10 13 10/10/2013 11:30 Page 32 Register your new TP product on line now at www.tptoys.com/product registration Thank you for purchasing this TP product. To find out all about your product guarantee and register your purchase, please visit www.tptoys.com/productregistration.
  • Seite 33 TP345 Castlewood Double Swing Arm (Seats not included) INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE PLEASE RETAIN FOR FUTURE REFERENCE. TP345 Castlewood Double Swing Arm Important! These instructions must be followed for safe assembly and use. Please retain for future reference. Important! Vous devez suivre ces instructions pour que le montage et l’utilisation se fassent en toute sécurité.

  • Seite 34: Maintenance

    INSTRUCTIONS FOR ASSEMBLY, MAINTENANCE AND USE OF TP TOYS warmer and sunnier weather, parts can become hot, and the temperature should be regularly checked during play, especially metal parts and slides. If there is any doubt over safety then the Please read carefully and keep all enclosed information for future reference.

  • Seite 35: Mantenimiento

    INSTRUCCIONES DE MONTAJE, MANTENIMIENTO Y USO DE LOS JUGUETES TP pegarse al metal a temperaturas inferiores a los 0°C. En días calurosos y soleados, puede que algunas piezas se recalienten, por lo que la temperatura del juguete debe comprobarse con Lea detenidamente toda la información adjunta y consérvela para futuras frecuencia mientras se usa, especialmente las piezas metálicas y los toboganes.
  • Seite 36 Unlike steel, wood is a natural, organic material and each piece will be unique, bearing its own knots, cracks and variations in colour and, unlike steel, wood will react significantly to changes in atmospheric conditions. Wood will expand and contract as fluctuations of temperature and humidity affect the water content of the cell structure. In warm sunny weather it will shrink and in wet weather it will expand.
  • Seite 37 Instruction Guide Read Instructions Before Starting Hidden Lines Sort Fixings Sort Parts Need Help? Visit www.tptoys.com TP Customer Services: (English Speaking) TP Castlewood Double Swing Arm TP345 Castlewood Double Swing Arm IN3102 Issue H 21.08.17.indd 5 21/08/2017 14:15...
  • Seite 38 Contents - Please check Tools - You will need: Vous aurez besoin de: Siete Pregati di Controllare il Contenuto Sie benötigen: Conteúdos - Por favor verifique Verifique El Contenido Avrete bisngno: Inhalt - Bitte Überprüfen Contenu - Veuillez Vérifier Precisará: Vai precisar: 13mm 10mm...
  • Seite 39 PM8255 MW2053 Upright (1920mm) FA7184 FA5174 FA5218 FA8441 FA8292 M8 × 124mm PM8312 M8 Nyloc Nut M8 plain nut M8 Spring M8 Washer (25mm o/dia) Washer Branding Badge Pack PR8971 ×1 PR8971 Branding badge M8 Nyloc Nut M8 Washer (25mm) M8 Washer (25mm) M8 Spring Washer M8 Plain Nut...
  • Seite 40 MW0023 (2170mm) FA5174 FA7184 FA8445 FA9219 M8 Washer M8 × 80mm M8 × 60mm M8 Nyloc Nut (25mm o/dia) Check FA7184 MW0026 M8 Washer (690mm) (25mm o/dia) FA8439 M8 × 70mm FA8443 Nº12 × 63mm (2½”) TP Castlewood Double Swing Arm TP345 Castlewood Double Swing Arm IN3102 Issue H 21.08.17.indd 8 21/08/2017 14:15...
  • Seite 41 FA7184 FA8439 M8 × 70mm MW2054 M8 Washer (905 mm) (25mm o/dia) MW2054 MW2054 (905mm) (905mm) Check TP Castlewood Double Swing Arm TP345 Castlewood Double Swing Arm IN3102 Issue H 21.08.17.indd 9 21/08/2017 14:15...
  • Seite 42 FA7184 FA5174 PM8312 M8 Washer M8 Nyloc Nut (25mm o/dia) Minimum Minimum 350mm 350mm 90 ° TP Castlewood Double Swing Arm TP345 Castlewood Double Swing Arm IN3102 Issue H 21.08.17.indd 10 21/08/2017 14:15...
  • Seite 43 Safe Play / Staking FA8380 PR5069 M8 x 40mm Coach screw FA7184 M8 Washer (25mm o/dia) 45 ° 30cm 45 ° 30cm 30cm Set the stakes in concrete (as shown). Never set the legs of the playset in concrete. Positioning / Freespace / Safe Play Diagram Recommended Free Space: The Safe Play Area refers to the zone extending 200cm (2 metres) beyond the toy on all sides and 250cm (2.5 metres)
  • Seite 44 Register your new TP product on line now at www.tptoys.com/productregistration Thank you for purchasing this TP product. To find out all about your product guarantee and register your purchase, please visit www.tptoys.com/productregistration. We want to give you the very best service. By registering your purchase now, we will be able to deal with any guarantee issues very quickly and efficiently in the future.
