Tally Dascom MIP480 Benutzerhandbuch Seite 98

Command Sets
Function
Horizontal Control
Space
Backspace
Carriage return
Select 10cpi
Elite characters on
Proportionally spaced characters on/off
(on: n = 1, off: n = 0)
Vertical Control
Line feed
Form feed
Advance paper n/216 inch (1 ≤ n ≤ 255)
Advance paper n/180 inch (in AG mode)
(1 ≤ n ≤ 255)
Set line spacing to 1/8 lines
Set line spacing to 7/72 inch
Set line spacing to n/216 inch
(0 ≤ n ≤ 255)
Set line spacing to n/180 inch (in AG mode)
(0 ≤ n ≤ 255)
Preset line spacing to n/72 inch
(1 ≤ n ≤ 255)
Preset line spacing to n/60 inch (in AG mode)
(1 ≤ n ≤ 255)
Set line spacing to 1/6 inch or to the value
preset by line spacing command ESC A (n)
Change graphics line spacing base to
1/216 or 1/180 inch (for ESC J and ESC 3)
m 1 = 4, m 2 = 0
0 ≤ t 1 ≤ 255, 0 ≤ t 2 ≤ 255, t 3 = 0
t 4 = 180 or 216
Reverse line feed
Tabulation
Horizontal tab execution
Set horizontal tabs
The values of n 1 to n k in this command are the
ASCII values of the print columns (at the current character
width) at which tabs are to be set.
(1 ≤ n ≤ 255) (1 ≤ k ≤ 28)
Clear all horizontal tabs
Move print position right by n/120 inch
(0 ≤ n 1 , n 2 ≤ 255) (n = n 1 + n 2 X 256)
C-4
Command
SP
BS
CR
DC2 :
ESC :
ESC P (n)
LF
FF
ESC J (n)
ESC J (n)
ESC 0
ESC 1
ESC 3 (n)
ESC 3 (n)
ESC A (n)
ESC A (n)
ESC 2
ESC [ \ (m 1 ) (m 2 ) (t 1 ) ... (t 4 )
ESC ]
HT
ESC D (n 1 ) ... (n k ) NUL
ESC D NUL
ESC d (n 1 ) (n 2 )
