Quick Start
Thank you for purchasing the MSI
X299M-A PRO/ X299M-A PRO
®
AC
motherboard. This Quick Start section provides demonstration
diagrams about how to install your computer. Some of the
installations also provide video demonstrations. Please link to the
URL to watch it with the web browser on your phone or tablet. You
may have even link to the URL by scanning the QR code.
Kurzanleitung
Danke, dass Sie das MSI
X299M-A PRO/ X299M-A PRO AC
®
Motherboard gewählt haben. Dieser Abschnitt der Kurzanleitung
bietet eine Demo zur Installation Ihres Computers. Manche
Installationen bieten auch die Videodemonstrationen. Klicken Sie
auf die URL, um diese Videoanleitung mit Ihrem Browser auf Ihrem
Handy oder Table anzusehen. Oder scannen Sie auch den QR Code
mit Ihrem Handy, um die URL zu öffnen.
Présentation rapide
Merci d' avoir choisi la carte mère MSI
X299M-A PRO/ X299M-A
®
PRO
AC. Ce manuel fournit une rapide présentation avec des
illustrations explicatives qui vous aideront à assembler votre
ordinateur. Des tutoriels vidéo sont disponibles pour certaines
étapes. Cliquez sur le lien fourni pour regarder la vidéo sur votre
téléphone ou votre tablette. Vous pouvez également accéder au lien
en scannant le QR code qui lui est associé.
Быстрый старт
Благодарим вас за покупку материнской платы MSI
®
AC. В этом разделе представлена
X299M-A PRO/ X299M-A PRO
информация, которая поможет вам при сборке комьютера.
Для некоторых этапов сборки имеются видеоинструкции.
Для просмотра видео, необходимо открыть
соответствующую ссылку в веб-браузере на вашем телефоне
или планшете. Вы также можете выполнить переход по
ссылке, путем сканирования QR-кода.
I
Quick Start

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für MSI X299M-A PRO

  • Seite 1 Handy oder Table anzusehen. Oder scannen Sie auch den QR Code mit Ihrem Handy, um die URL zu öffnen. Présentation rapide Merci d’ avoir choisi la carte mère MSI X299M-A PRO/ X299M-A ® AC. Ce manuel fournit une rapide présentation avec des illustrations explicatives qui vous aideront à...
  • Seite 2 Installing a Processor/ Installation des Prozessors/ Installer un processeur/ Установка процессора https://youtu.be/ecdkLMmkya4 Quick Start...
  • Seite 3 Installing DDR4 memory/ Installation des DDR4-Speichers/ Installer une mémoire DDR4/ Установка памяти DDR4 http://youtu.be/T03aDrJPyQs DIMMB1 DIMMB1 DIMMB2 DIMMA1 DIMMA1 DIMMA1 DIMMA2 Quick Start...
  • Seite 4 Connecting the Front Panel Header/ Anschließen der Frontpanel-Stiftleiste/ Connecter un connecteur du panneau avant/ Подключение разъемов передней панели http://youtu.be/DPELIdVNZUI HDD LED + Power LED + HDD LED - Power LED - Reset Switch Power Switch Reset Switch Power Switch JFP1 Reserved No Pin JFP1...
  • Seite 5 Installing the Motherboard/ Installation des Motherboards/ Installer la carte mère/ Установка материнской платы BAT1 Quick Start...
  • Seite 6 Installing SATA Drives/ Installation der SATA-Laufwerke/ Installer le disque dur SATA/ Установка дисков SATA http://youtu.be/RZsMpqxythc Quick Start...
  • Seite 7 Installing a Graphics Card/ Einbau der Grafikkarte/ Installer une carte graphique/ Установка дискретной видеокарты http://youtu.be/mG0GZpr9w_A Quick Start...
  • Seite 8 Connecting Peripheral Devices/ Peripheriegeräte/ Connecter un périphérique anschliessen/ Подключение периферийных устройств (AC version only) VIII Quick Start...
  • Seite 9 Connecting the Power Connectors/ Stromanschlüsse anschliessen/ Connecter les câbles du module d’ alimentation/ Подключение разъемов питания http://youtu.be/gkDYyR_83I4 ATX_PWR1 CPU_PWR1 PCIE_PWR1 Quick Start...
  • Seite 10: Power On/ Einschalten/ Mettre Sous-Tension/ Включение Питания

    Power On/ Einschalten/ Mettre sous-tension/ Включение питания Quick Start...
  • Seite 11: Inhaltsverzeichnis

    Contents Safety Information ....................3 Specifications ......................4 Rear I/O Panel ....................... 9 LAN Port LED Status Table..................9 Audio Ports Configuration ..................9 Realtek HD Audio Manager .................. 10 Installing Antennas (for AC version) ..............12 Overview of Components ..................13 CPU Socket ......................
  • Seite 12 Software Description ................... 40 Installing Windows 10 ..................40 ® Installing Drivers ....................40 Installing Utilities ....................40 Contents...
  • Seite 13: Safety Information

    Safety Information y The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. y Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start.
  • Seite 14: Specifications

    Supports Intel Extreme Memory Profile (XMP) ® * For the latest information about memory, please visit http://www.msi.com y 3x PCIe 3.0 x16 slots Expansion Slots ƒ Support x16/ x0/ x0, x8/ x8/ x0 or x8, x4, x4 mode with the 16-lane CPU.
  • Seite 15 * M.2 slots and SATA ports maximum support 2x M.2 PCIe SSD + 8x SATA HDD. Please refer to page 18 for M.2 & SATA Combination table. **Please refer to the Intel Optane™ Memory Configuration Guide on MSI ® website.
  • Seite 16 Continued from previous page y 1x 24-pin ATX main power connector y 1x 8-pin ATX 12V power connector y 1x 6-pin ATX 12V power connector y 8x SATA 6Gb/s connectors y 2x M.2 slots (Key M) y 1x M.2 slot (Key E) y 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) y 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1...
  • Seite 17 SMART TOOL y X-BOOST y MYSTIC LIGHT Software y RAMDISK y Network Manager y DPC Latency Tuner y FAST BOOT y CPU-Z MSI GAMING y Intel Extreme Tuning Utility ® y Google Chrome ,Google Toolbar, Google Drive ™ y Norton Internet Security Solution ™...
  • Seite 18 LED ƒ Mystic Light Extension ƒ Mystic light SYNC ƒ EZ DEBUG LED y Protection ƒ PCI-E Steel Armor MSI Special y Performance Features ƒ Multi GPU – SLI Technology ƒ Multi GPU – CrossFire Technology ƒ DDR4 Boost ƒ...
  • Seite 19: Rear I/O Panel

    Rear I/O Panel Wi-Fi Antenna connectors Audio Ports (for AC version) PS/2 Mouse USB 2.0 USB 3.1 Gen2 Optical USB 3.1 Gen1 PS/2 Keyboard Type-C S/PDIF-Out Type-A USB 3.1 Gen2 USB 3.1 Gen1 Type-A Type-A LAN Port LED Status Table Link/ Activity LED Speed LED Status...
  • Seite 20: Realtek Hd Audio Manager

    Realtek HD Audio Manager After installing the Realtek HD Audio driver, the Realtek HD Audio Manager icon will appear in the system tray. Double click on the icon to launch. Device Selection Advanced Settings Jack Status Application Enhancement Main Volume Connector Strings Profiles...
  • Seite 21 Audio jacks to headphone and microphone diagram Audio jacks to stereo speakers diagram AUDIO INPUT Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Rear Front Side Center/ Subwoofer Rear I/O Panel...
  • Seite 22: Installing Antennas (For Ac Version)

    Installing Antennas (for AC version) 1. Screw the antennas tight to the Wi-Fi antenna connectors as shown. 2. Place the antennas as high as possible. Rear I/O Panel...
  • Seite 23: Overview Of Components

    Overview of Components DIMMA2 CPU_PWR1 DIMMA1 CPU Socket DIMMB2 CPU_FAN1 DIMMB1 SYS_FAN1 PUMP_FAN1 ATX_PWR1 JUSB4 M2_2 JUSB3 PCIE_PWR1 PCI_E1 BIOS_SW1 SATA▼1▲2 M2_1 SATA▼3▲4 PCI_E2 SATA▼5▲6 BAT1 PCI_E3 SATA▼7▲8 JBAT1 JLED1 JUSB1 JUSB2 SYSFAN3 SYSFAN2 JFP1 JAUD1 JCI1 JFP2 POWER1 JTPM1 Overview of Components...
  • Seite 24: Cpu Socket

    Always unplug the power cord from the power outlet before installing or removing the CPU. Please retain the CPU protective cap after installing the processor. MSI will deal with Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.
  • Seite 25: Dimm Slots

    DIMM Slots DIMMA2 DIMMB2 Channel A Channel B DIMMA1 DIMMB1 Memory module installation recommendation DIMMB1 DIMMB1 DIMMB2 DIMMA1 DIMMA1 DIMMA1 DIMMA2 Important To ensure system stability for Dual channel mode, memory modules must be of the same type, number and density. And for every channel, the odd number DIMM slot must to be installed first.
  • Seite 26: Pci_E1~3: Pcie Expansion Slots

    For a single PCIe x16 expansion card installation with optimum performance, using the PCI_E1 slot is recommended. If you install a large and heavy graphics card, you need to use a tool such as MSI Gaming Series Graphics Card Bolster to support its weight and to prevent deformation of the slot.
  • Seite 27: M2_1~2: M.2 Slots (Key M)

    M2_1~2: M.2 Slots (Key M) Important Intel RST only supports PCIe M.2 SSD with UEFI ROM. ® Intel Optane™ Memory Ready for all M.2 slots. ® Video Demonstration M2_2 Watch the video to learn how to Install M.2 M2_1 module. http://youtu.be/JCTFABytrYA Installing M.2 module 1.
  • Seite 28: Sata1~8: Sata 6Gb/S Connectors

    SATA1~8: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 SATA8 SATA7 Important Please do not fold the SATA cable at a 90-degree angle. Data loss may result during transmission otherwise.
  • Seite 29 M.2 slots with examples of various combination possibilities 2xM.2 PCIe+ 8xSATA 1xM.2 SATA+ 1xM.2 PCIe+ 7xSATA M.2 PCIe M.2 SATA 1xM.2 PCIe+ 1xM.2 SATA+ 7xSATA 2xM.2 SATA+ 6xSATA M.2 PCIe M.2 SATA Overview of Components...
  • Seite 30: Cpu_Pwr1, Atx_Pwr1, Pcie_Pwr1: Power Connectors

    CPU_PWR1, ATX_PWR1, PCIE_PWR1: Power Connectors These connectors allow you to connect an ATX power supply. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V...
  • Seite 31: Jfp1, Jfp2: Front Panel Connectors

    JFP1, JFP2: Front Panel Connectors These connectors connect to the switches and LEDs on the front panel. JFP1 HDD LED + Power LED + HDD LED - Power LED - Reset Switch Power Switch Reset Switch Power Switch Reserved No Pin Speaker - Buzzer + JFP2...
  • Seite 32: Jusb1~2: Usb 2.0 Connectors

    JUSB1~2: USB 2.0 Connectors These connectors allow you to connect USB 2.0 ports on the front panel. USB0- USB1- USB0+ USB1+ Ground Ground No Pin Important Note that the VCC and Ground pins must be connected correctly to avoid possible damage.
  • Seite 33: Cpu_Fan1, Pump_Fan1, Sys_Fan1~3: Fan Connectors

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~3: Fan Connectors Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode. PWM Mode fan connectors provide constant 12V output and adjust fan speed with speed control signal. DC Mode fan connectors control fan speed by changing voltage. When you plug a 3-pin (Non-PWM) fan to a fan connector in PWM mode, the fan speed will always maintain at 100%, which might create a lot of noise.
  • Seite 34: Jci1: Chassis Intrusion Connector

    JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis intrusion event (default) Using chassis intrusion detector 1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis. 2.
  • Seite 35: Bios_Sw1: Multi-Bios Switch

    When BIOS updating fails or causes the computer non-bootable, you can recover the failed BIOS by the steps below. Before recovering, please download the latest BIOS file that matches your motherboard model from MSI website. And then save the BIOS file to the root of the USB flash drive.
  • Seite 36: Jbat1: Clear Cmos (Reset Bios) Jumper

    JBAT1: Clear CMOS (Reset BIOS) Jumper There is CMOS memory onboard that is external powered from a battery located on the motherboard to save system configuration data. If you want to clear the system configuration, set the jumper to clear the CMOS memory. Keep Data Clear CMOS/ Reset BIOS...
  • Seite 37: Jled1: Rgb Led Connector

    Always turn off the power supply and unplug the power cord from the power outlet before installing or removing the RGB LED strip. Please use MSI’ s software to control the extended LED strip. Overview of Components...
  • Seite 38: Onboard Leds

    Onboard LEDs EZ Debug LEDs These LEDs indicate the status of key components during booting process. When an error is occurred, the corresponding LED stays lit until the problem is solved. CPU - indicates CPU is not detected, fail or non- supported.
  • Seite 39: Bios Setup

    Press Delete key, when the Press DEL key to enter Setup Menu, F11 to enter Boot Menu message appears on the screen during the boot process. y Use MSI FAST BOOT application. Click on GO2BIOS button and choose OK. The system will reboot and enter BIOS setup directly.
  • Seite 40: Resetting Bios

    Updating BIOS Updating BIOS with M-FLASH Before updating: Please download the latest BIOS file that matches your motherboard model from MSI website. And then save the BIOS file into the USB flash drive. Updating BIOS: 1. Press Del key to enter the BIOS Setup during POST.
  • Seite 41: Ez Mode

    EZ Mode At EZ mode, it provides the basic system information and allows you to configure the basic setting. To configure the advanced BIOS settings, please enter the Advanced Mode by pressing the Setup Mode switch or F7 function key. XMP switch Setup Mode switch Screenshot...
  • Seite 42 y Information display - click on the CPU, Memory, Storage, Fan Info and Help buttons on left side to display related information. y Function buttons - enable or disable the LAN Option ROM, M.2/Optane Genie, Hardcore mode, AHCI, RAID, CPU Fan Fail Warning Control and BIOS Log Review by clicking on their respective button.
  • Seite 43: Advanced Mode

    Advanced Mode Press Setup Mode switch or F7 function key can switch between EZ Mode and Advanced Mode in BIOS setup. XMP switch Setup Mode switch Screenshot Search Language System information OC GENIE 4 switch Boot device priority bar BIOS menu BIOS menu selection selection...
  • Seite 44: Oc Menu

    OC Menu This menu is for advanced users who want to overclock the motherboard. Important Overclocking your PC manually is only recommended for advanced users. Overclocking is not guaranteed, and if done improperly, it could void your warranty or severely damage your hardware. If you are unfamiliar with overclocking, we advise you to use OC GENIE 4 function for easy overclocking.
  • Seite 45 f Misc Setting* Press Enter, + or - key to open or close the following 3 items related to CPU features. f EIST [Enabled]* Enables or disables the Enhanced Intel SpeedStep Technology. ® [Enabled] Enables the EIST to adjust CPU voltage and core frequency dynamically.
  • Seite 46 f Advanced DRAM Configuration Press Enter to enter the sub-menu. User can set the memory timing for each/ all memory channel. The system may become un-stable or un-bootable after changing memory timing. If it occurs, please clear the CMOS data and restore the default settings.
  • Seite 47 fCPU Technology Support Press Enter to enter the sub-menu. The sub-menu shows the key features of installed CPU. Read only. f MEMORY-Z Press Enter to enter the sub-menu. This sub-menu displays all the settings and timings of installed memory. You can also access this information menu at any time by pressing [F5].
  • Seite 48 fAdjacent Cache Line Prefetch [Enabled] Enables or disables the CPU hardware prefetcher (MLC Spatial prefetcher). [Enabled] Enables adjacent cache line prefetching for reducing the cache latency time and tuning the performance to the specific application. [Disabled] Enables the requested cache line only. fCPU AES Instructions [Enabled] Enables or disables the CPU AES (Advanced Encryption Standard-New Instructions) support.
  • Seite 49 fIntel Turbo Boost [Enabled] Enables or disables the Intel Turbo Boost. This item is for Normal mode and ® appears when a CPU that support Turbo Boost is installed. [Enabled] Enables this function to boost CPU performance automatically over specification when system request the highest performance state. [Disabled] Disables this function.
  • Seite 50: Software Description

    7. Follow the instructions on the screen to install Windows ® Installing Drivers 1. Start up your computer in Windows ® 2. Insert MSI Driver Disc into your optical drive. ® 3. The installer will automatically appear and it will find and list all necessary drivers.
  • Seite 51 Inhalt Sicherheitshinweis ....................3 Spezifikationen ...................... 4 Rückseite E/A ......................9 LAN Port LED Zustandstabelle ................9 Konfiguration der Audioanschlüsse ............... 9 Realtek HD Audio Manager .................. 10 Antennen installieren (für AC Version) ..............12 Übersicht der Komponenten ................13 CPU Sockel ......................
  • Seite 52 Softwarebeschreibung ..................40 Installation von Windows 10 ................40 ® Installation von Treibern ..................40 Installation von Utilities ..................40 Inhalt...
  • Seite 53: Sicherheitshinweis

    Sicherheitshinweis y Die im Paket enthaltene Komponenten sind der Beschädigung durch elektrostatischen Entladung (ESD). Beachten Sie bitte die folgenden Hinweise, um die erfolgreichen Computermontage sicherzustellen. y Stellen Sie sicher, dass alle Komponenten fest angeschlossen sind. Lockere Steckverbindungen können Probleme verursachen, zum Beispiel: Der Computer erkennt eine Komponente nicht oder startet nicht.
  • Seite 54: Spezifikationen

    2133 MHz* y Unterstützt Intel Extreme Memory Profile (XMP) ® * Weitere Informationen zu kompatiblen Speicher finden Sie unter: http://www. msi.com y 3x PCIe 3.0 x16-Steckplätze Erweiterung- ƒ Unterstützung für x16/ x0/ x0, x8/ x8/ x0 oder x8, x4, x4 anschlüsse Modi mit einer CPU die über 16-Lanes verfügt.
  • Seite 55: Aufbewahrung

    PCIe SSD + 8x SATA HDD. Auf der Seite 18 finden Sie die M.2- & SATA- Kombinationstabelle. **Weitere Informationen finden Sie die Installationsanleitung des Intel Optane ® ™ Speicher unter: www.msi.com . Intel X299 Chipsatz ® y Unterstützt RAID 0, RAID 1, RAID 5 und RAID 10 für SATA Speichergeräte RAID y Unterstützt RAID 0 und RAID 1 für M.2 Speichergeräte*...
  • Seite 56 Fortsetzung der vorherigen Seite y 1x 24-poliger ATX Stromanschluss y 1x 8-poliger ATX12V Stromanschluss y 1x 6-poliger ATX12V Stromanschluss y 8x SATA 6Gb/s Anschlüsse y 2x M.2 Steckplätze (Key M) y 1x M.2 Steckplatz (Key E) y 2x USB 2.0 Anschlüsse (unterstützt zusätzliche 4 USB 2.0-Ports) y 2x USB 3.1 Gen1 Anschlüsse (unterstützt zusätzliche 4 USB 3.1 Gen1-Ports)
  • Seite 57 SMART TOOL y X-BOOST y MYSTIC LIGHT Software y RAMDISK y Network Manager y DPC Latency Tuner y FAST BOOT y CPU-Z MSI GAMING y Intel Extreme Tuning Utility ® y Google Chrome , Google Toolbar, Google Drive ™ y Norton Internet Security Solution ™...
  • Seite 58 ƒ EZ DEBUG LED y Schutz ƒ PCI-E Steel Armor Besondere y Leistung Funktionen von MSI ƒ Multi GPU – SLI Technologie ƒ Multi GPU – CrossFire Technologie ƒ DDR4 Boost ƒ USB Anschluss mit Typ A+C ƒ Lightning USB mit ASM3142 y Stabilität...
  • Seite 59: Rückseite E/A

    Rückseite E/A Wi-Fi Antennenanschlüsse Audioanschlüsse (für AC Version) PS/2 Maus USB 2.0 USB 3.1 Gen2 Optischer S/PDIF- USB 3.1 Gen1 PS/2 Tastatur Typ-C Ausgang Typ-A USB 3.1 Gen2 USB 3.1 Gen1 Typ-A Typ-A LAN Port LED Zustandstabelle Verbindung/ Aktivität LED Geschwindigkeit LED Zustand Bezeichnung...
  • Seite 60: Realtek Hd Audio Manager

    Realtek HD Audio Manager Nach der Installation des Realtek HD Audio-Treibers, wird das Symbol Realtek HD Audio Manager in der Taskleiste angezeigt. Klicken Sie doppelt auf dieses Symbol, um das Programm zu starten. Geräteauswahl Erweiterte Einstellungen Verbindungs- status Optimierungen Lautstärke Anschlüsse Profil y Geräteauswahl - Ermöglicht die Auswahl der Audio-Ausgangs Quelle.
  • Seite 61: Audiobuchsen Für Stereo-Lautsprecher

    Audiobuchsen für den Anschluss von einem Kopfhörer und Mikrofon Audiobuchsen für Stereo-Lautsprecher AUDIO INPUT Audiobuchsen für 7,1 Kanal Anlage AUDIO INPUT Rear Front Side Center/ Subwoofer Rückseite E/A...
  • Seite 62: Antennen Installieren (Für Ac Version)

    Antennen installieren (für AC Version) 1. Schrauben Sie, wie gezeigt, die Antennen fest an die Wi-Fi Antennenanschlüsse. 2. Positionieren Sie die Antennen so hoch wie möglich. Rückseite E/A...
  • Seite 63: Übersicht Der Komponenten

    Übersicht der Komponenten DIMMA2 CPU_PWR1 DIMMA1 CPU Sockel DIMMB2 CPU_FAN1 DIMMB1 SYS_FAN1 PUMP_FAN1 ATX_PWR1 JUSB4 M2_2 JUSB3 PCIE_PWR1 PCI_E1 BIOS_SW1 SATA▼1▲2 M2_1 SATA▼3▲4 PCI_E2 SATA▼5▲6 BAT1 PCI_E3 SATA▼7▲8 JBAT1 JLED1 JUSB1 JUSB2 SYSFAN3 SYSFAN2 JFP1 JAUD1 JCI1 JFP2 POWER1 JTPM1 Übersicht der Komponenten...
  • Seite 64: Cpu Sockel

    Sie jedoch bitte sicher, dass die betroffenen Komponenten mit den abweichenden Einstellungen während des Übertaktens zurecht kommen. Von jedem Versuch des Betriebes außerhalb der Produktspezifikationen kann nur abgeraten werden. MSI übernehmt keinerlei Garantie für die Schäden und Risiken, die aus einem unzulässigem Betrieb oder einem Betrieb außerhalb der Produktspezifikation resultieren.
  • Seite 65: Übersicht Der Komponenten

    DIMM-Steckplätze DIMMA2 DIMMB2 Kanal A Kanal B DIMMA1 DIMMB1 Mehrere Grafikkarten Einbauempfehlung DIMMB1 DIMMB1 DIMMB2 DIMMA1 DIMMA1 DIMMA1 DIMMA2 Wichtig Stellen Sie im Dual-Kanal-Modus bitte sicher, dass Sie Module des gleichen Typs und identischer Speicherdichte in den DIMM Slots unterschiedlicher Kanäle verwenden. Für jeden Kanal muss zuerst die ungerade Anzahl der DIMM-Steckplätze installiert werden.
  • Seite 66: Pci_E1~3: Pcie Erweiterungssteckplätze

    PCI_E1~3: PCIe Erweiterungssteckplätze PCI_E1: PCIe 3.0 x16/ x8 PCI_E2: PCIe 3.0 x8/ x4 BAT1 PCI_E3: PCIe 3.0 x4 Tabelle der PCIe Bandbreiten Graphikkarte Einzel* 2-Wege* 2-Wege PCI_E1 @ 3.0 x16 @ 3.0 x8 @ 3.0 x8 PCI_E2 3.0 x0 @ 3.0 x8 3.0 x4 PCI_E3 3.0 x0...
  • Seite 67: M2_1~2: M.2 Steckplätze (Key M)

    M2_1~2: M.2 Steckplätze (Key M) Wichtig Intel RST unterstützt nur PCIe M.2 SSD mit UEFI ROM. ® Intel Optane Technik unterstützt alle M.2 Steckplätze. ® ™ Video-Demonstration M2_2 Eine anschauliche Darstellung zur M2_1 Installation eines M.2 Moduls finden Sie im Video.
  • Seite 68: Sata1~8: Sata 6Gb/S Anschlüsse

    SATA1~8: SATA 6Gb/s Anschlüsse Dieser Anschluss basiert auf der Hochgeschwindigkeitsschnittstelle SATA 6Gb/s. Pro Anschluss kann ein SATA Gerät angeschlossen werden. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 SATA8 SATA7 Wichtig Knicken Sie das SATA-Kabel nicht in einem 90° Winkel. Datenverlust könnte die Folge sein.
  • Seite 69: Steckplätze Mit Beispielen Zu Den Verschiedenen Kombinationsmöglichkeiten

    M.2 Steckplätze mit Beispielen zu den verschiedenen Kombinationsmöglichkeiten 2xM.2 PCIe+ 8xSATA 1xM.2 SATA+ 1xM.2 PCIe+ 7xSATA M.2 PCIe M.2 SATA 1xM.2 PCIe+ 1xM.2 SATA+ 7xSATA 2xM.2 SATA+ 6xSATA M.2 PCIe M.2 SATA Übersicht der Komponenten...
  • Seite 70: Cpu_Pwr1, Atx_Pwr1, Pcie_Pwr1: Stromanschlüsse

    CPU_PWR1, ATX_PWR1, PCIE_PWR1: Stromanschlüsse Mit diesen Anschlüssen verbinden Sie die ATX Stromstecker. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground +12V Ground...
  • Seite 71: Jfp1, Jfp2: Frontpanel-Anschlüsse

    Bitte beachten Sie, dass Sie die mit „Stromführende Leitung “ und „Erdleitung “ bezeichneten Pins korrekt verbinden müssen, ansonsten kann es zu Schäden kommen. Um ein iPad, iPhone und einen iPod über USB-Anschlüsse aufzuladen, installieren Sie bitte die MSI SUPER CHARGER Software. ® Übersicht der Komponenten...
  • Seite 72: Jusb1~2: Usb 2.0 Anschlüsse

    JUSB1~2: USB 2.0 Anschlüsse Mit diesen Anschlüssen können Sie die USB 2.0 Anschlüsse auf dem Frontpanel verbinden. USB0- USB1- USB0+ USB1+ Ground Ground No Pin Wichtig Bitte beachten Sie, dass Sie die mit VCC (Stromführende Leitung) und Ground (Erdleitung) bezeichneten Pins korrekt verbinden müssen, ansonsten kann es zu Schäden kommen.
  • Seite 73: Cpu_Fan1, Pump_Fan1, Sys_Fan1~3: Stromanschlüsse Für Lüfter

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~3: Stromanschlüsse für Lüfter Diese Anschlüsse können im PWM (Pulse Width Modulation) Modus oder Spannungsmodus betrieben werden. Im PWM-Modus bieten die Lüfteranschlüsse konstante 12V Ausgang und regeln die Lüftergeschwindigkeit per Drehzahlsteuersignal. Im DC-Modus bestimmen die Lüfteranschlüsse die Lüftergeschwindigkeit durch Ändern der Spannung. Wenn Sie ein 3-Pin (Non-PWM) Lüfter an einen PWM-Modus Lüfteranschluss anschließen, läuft der Lüfter mit höchster Drehzahl und kann unangenehm laut werden.
  • Seite 74: Jci1: Gehäusekontaktanschluss

    JCI1: Gehäusekontaktanschluss Dieser Anschluss wird mit einem Kontaktschalter verbunden. Normal Löse den Gehäuseeingriff aus (Standardwert) Gehäusekontakt-Detektor verwenden 1. Schließen Sie den JCI1-Anschluss am Gehäusekontakt-Schalter/ Sensor am Gehäuse an. 2. Schließen Sie die Gehäuseabdeckung. 3. Gehen Sie zu BIOS > SETTINGS > Security > Chassis Intrusion Configuration. 4.
  • Seite 75: Bios_Sw1: Multi-Bios Schalter

    Sie die folgenden Schritte ausführen, um das BIOS wiederherzustellen. Vor Wiederherstellung laden Sie bitte die neueste BIOS-Version, die dem Motherboard-Modell entspricht, von der offiziellen MSI Website herunter. Und speichern Sie die BIOS-Datei im Root-Verzeichnis des USB-Flash-Speichers. 1. Schalten Sie den Computer aus.
  • Seite 76: Jbat1: Clear Cmos Steckbrücke (Reset Bios)

    JBAT1: Clear CMOS Steckbrücke (Reset BIOS) Der Onboard CMOS Speicher (RAM) wird durch eine externe Spannungsversorgung durch eine Batterie auf dem Motherboard versorgt, um die Daten der Systemkonfiguration zu speichern. Wenn Sie die Systemkonfiguration löschen wollen, müssen Sie die Steckbrücke für kurze Zeit umsetzen. Daten CMOS-Daten beibehalten...
  • Seite 77: Jled1: Rgb Led Anschluss

    LED-Streifens maximal 2 Meter betragen darf um eine Verdunkelung der LED zu verhindern. Schalten Sie die Stromversorgung aus und ziehen Sie das Netzkabel ab, bevor Sie die RGB-LED-Streifen ein- und ausbauen. Bitte verwenden Sie die MSI-Software zur Steuerung des LED-Leuchtstreifens. Übersicht der Komponenten...
  • Seite 78: Onboard-Leds

    Onboard-LEDs EZ Debug LEDs Diese LEDs zeigen den Status der Hauptkomponenten während des Boot-Vorgangs an. Im Falle eines Fehlers, leuchtet die entsprechende LED bis zur Lösung des Problems vorübergehend dauerhaft. CPU -CPU wird nicht erkannt, ist fehlerhaft oder nicht abgestützt. DRAM -DRAM wird nicht erkannt oder ist fehlerhaft.
  • Seite 79: Bios-Setup

    Während des BOOT-Vorgangs drücken Sie die Taste ENTF, wenn die Meldung Press DEL key to enter Setup Menu, F11 to enter Boot Menu erscheint. y Verwenden Sie die MSI FAST BOOT Anwendung. Klicken Sie die GO2BIOS-Taste und drücken OK. Das System startet neu und geht direkt ins BIOS.
  • Seite 80: Reset Des Bios

    Aktualisierung des BIOS mit dem M-FLASH-Programm Vorbereitung: Laden Sie bitte die neueste BIOS Version, die dem Motherboard-Modell entspricht, von der offiziellen MSI Website herunter und speichern Sie die BIOS-Datei auf USB-Flash- Laufwerk. BIOS-Aktualisierungsschritte: 1. Drücken Sie während des POST-Vorgangs die Taste (Entf), um das BIOS zu öffnen.
  • Seite 81: Ez Modus

    EZ Modus Im EZ-Modus können Sie die Grundinformationen des Systems einsehen und grundlegende Einstellungen konfigurieren. Um sich die erweiterten BIOS- Einstellungen anzeigen zu lassen, aktivieren Sie bitte den Erweiterten Modus durch Drücken des Setup Modus Schalter oder der Funktionstaste F7. XMP Schalter Setup Modus Schalter Screenshot...
  • Seite 82 y Boot-Geräte Prioritätsleiste - Sie können die Gerätesymbole verschieben, um die Startreihenfolge zu ändern. Die Bootreihenfolge sind mit “hoch” (links) bis “niedrig” (rechts) bezeichnet. y Informationsanzeige - Klicken Sie auf die Schaltfläche CPU, Memory, Storage, Fan Info und Help auf der linken Seite, um die jeweiligen Informationen anzuzeigen. y Funktionstasten - Aktivieren oder deaktivieren Sie LAN Option ROM, M.2/Optane Genie, Hardcore Mode, AHCI, RAID, CPU Fan Fail Warning Control und BIOS Log Review durch Anklicken der zugehörigen Schaltfläche.
  • Seite 83: Erweiterter Modus

    Erweiterter Modus Drücken Sie den Setup Modus Schalter oder die Funkionstaste F7, um zwischen dem EZ-Modus und Erweiterten-Modus im BIOS-Setup zu wechseln. XMP Schalter Setup Modus Schalter Screenshot Suchen Sprache System- information OC GENIE 4 Schalter Bootgeräte- Prioritätsleiste BIOS-Menü BIOS-Menü -Auswahl -Auswahl Menüanzeige...
  • Seite 84: Oc Menü

    OC Menü In diesem Menü können Benutzer das BIOS anpassen und das Mainboard übertakten. Bitte führen Sie nur Änderungen durch, wenn Sie sich über das Ergebnis im Klaren sind. Sie sollten Erfahrung beim Übertakten haben, da Sie sonst das Motherboard oder Komponenten des Systems beschädigen können.
  • Seite 85 f Ring Ratio [Auto] Setzen Sie den Ring Ratio. Der erlaubte Wertebereich ist abhängig von der installierten CPU. f Adjusted Ring Frequency Zeigt die angepasste Ring Frequenz. Nur Anzeige – keine Änderung möglich. f Misc Setting* Drücken Sie die Enter, + oder - Taste, um die folgenden 3 Punkte des CPU-Funktionen zu öffnen oder zu schließen.
  • Seite 86 f Memory Try It ! [Disabled] „Memory Try It! “ kann die Speicherkompatibilität oder die Leistung verbessern indem optimierte Speichervoreinstellungen gewählt werden. f DRAM Timing Mode [Link] Wählt den Speicher-Timing-Modus aus. [Link] Ermöglicht die manuelle Konfigurieren des DRAM-Timing für alle Speicherkanäle.
  • Seite 87 ist, wird das BIOS die Spannungen automatisch einstellen oder Sie können es manuell einstellen. f CPU Memory Changed Detect [Enabled]* Aktiviert/Deaktiviert die Systemwarnmeldung beim Booten, wenn die CPU oder der Hauptspeicher ersetzt wurde. [Enabled] Das System zeigt eine Warnmeldung beim Systemstart und lädt die Default-Einstellungen für neue Geräte.
  • Seite 88 fIntel Virtualization Tech [Enabled] Aktiviert oder deaktiviert die Intel Virtualization Technologie. [Enabled] Aktiviert die Intel Virtualization-Technologie, die es mehreren Betriebssystemen ermöglicht, in voneinander unabhängigen Partitionen zu arbeiten. Das System kann als mehrere Systeme virtuell einsetzen. [Disabled] Deaktiviert diese Funktion. fIntel VT-D Tech [Disabled] Aktiviert oder deaktiviert die Intel VT-D (Intel Virtualization for Directed I/O) Technologie.
  • Seite 89 fPackage C State Limit [Auto] Hier können Sie einen CPU C-State-Modus für Stromsparen auswählen, wenn das System im Leerlauf ist. Die Optionen des C-States ist abhängig von der installierten CPU. Diese Option wird angezeigt, wenn Intel C-State aktiviert ist. fCFG Lock [Enabled] Sperren oder Entsperren des MSR 0xE2[15]s, des CFG Lock-Bits.
  • Seite 90: Softwarebeschreibung

    ® Installation von Treibern 1. Starten Sie Ihren Computer mit Windows ® 2. Legen Sie die MSI Treiber Disk in das optisches Laufwerk. ® 3. Der Installer wird automatisch erscheint und findet und finden Sie die benötigten Treiber in die Liste.
  • Seite 91 Table des matières Informations de sécurité ..................3 Spécifications ......................4 Panneau arrière Entrée/ Sortie ................9 Tableau explicatif de l’ état de la LED du port LAN ..........9 Configuration des ports audio ................9 Realtek HD Audio Manager .................. 10 Installation des antennes (pour la version AC) ............
  • Seite 92 Informations sur les logiciels................40 Installer Windows 10 ..................40 ® Installer les pilotes ....................40 Installer les utilitaires ..................40 Table des matières...
  • Seite 93: Informations De Sécurité

    Informations de sécurité y Les composants dans l’ emballage peuvent être endommagés par des décharges électrostatiques (ESD). Pour vous assurer de correctement monter votre ordinateur, veuillez vous référer aux instructions ci-dessous. y Assurez-vous de bien connecter tous les composants. En cas de mauvaise connexion, il se peut que l’...
  • Seite 94: Spécifications

    2133 MHz* y Support Intel Extreme Memory Profile (XMP) ® * Veuillez vous référer au site http://www.msi.com pour les dernières informations sur la mémoire. y 3 x slots PCIe 3.0 x16 Slots d’ extension ƒ Support le mode x16/ x0/ x0, x8/ x8/ x0 ou x8/ x4/ x4 avec un processeur supportant 16 lignes.
  • Seite 95 SATA. Référez-vous à la page 18 pour le tableau de combinaison M.2 et SATA. ** Veuillez vous référer au manuel de configuration de la mémoire Intel ® Optane™ sur le site MSI officiel. Chipset Intel X299 ®...
  • Seite 96: Connecteurs Internes

    Suite du tableau de la page précédente y 1 x connecteur d’ alimentation principal ATX 24 broches y 1 x connecteur d’ alimentation ATX 12V 8 broches y 1 x connecteur d’ alimentation ATX 12V 6 broches y 8 x connecteurs SATA 6 Gb/s y 2 x slots M.2 (Touche M) y 1 x slot M.2 (Touche E) y 2 x connecteurs USB 2.0 (support de 4 autres ports USB...
  • Seite 97 X-BOOST y MYSTIC LIGHT Logiciel y RAMDISK y Network Manager y DPC Latency Tuner y FAST BOOT y CPU-Z MSI GAMING y Intel Extreme Tuning Utility ® y Google Chrome , Google Toolbar et Google Drive ™ y Norton Internet Security Solution ™...
  • Seite 98 Suite du tableau de la page précédente y Audio ƒ Audio Boost 4 y Network ƒ Intel LAN avec Network Manager y Stockage ƒ Twin Turbo M.2 y Ventilateurs ƒ Ventilateurs pour la pompe ƒ Contrôle des ventilateurs y LED ƒ...
  • Seite 99: Panneau Arrière Entrée/ Sortie

    Panneau arrière Entrée/ Sortie Connecteurs d’ antenne Wi-Fi Ports Audio (pour la version AC) Souris PS/2 USB 2.0 USB 3.1 Gen2 Sortie S/PDIF USB 3.1 Gen1 Clavier PS/2 Type-C optique Type-A USB 3.1 Gen2 USB 3.1 Gen1 Type-A Type-A Tableau explicatif de l’ état de la LED du port LAN LED indiquant la connexion LED indiquant la vitesse et l’...
  • Seite 100: Realtek Hd Audio Manager

    Realtek HD Audio Manager Après l’ installation du pilote Realtek HD Audio, l’ icône Realtek HD Audio Manager apparaît dans la barre des tâches du système. Double-cliquez sur l’ icône pour lancer le programme. Sélection du périphérique Paramètres avancés Etat des prises Jack Amélioration d’...
  • Seite 101 Ilustration de l’ utilisation des ports audio dédiés au casque et au microphone Ilustration de l’ utilisation du port audio dédié aux haut-parleurs AUDIO INPUT Ilustration de l’ utilisation des ports audio dédiés aux haut-parleurs 7.1 AUDIO INPUT Rear Front Side Center/ Subwoofer...
  • Seite 102: Installation Des Antennes (Pour La Version Ac)

    Installation des antennes (pour la version AC) 1. Vissez fermement les antennes aux connecteurs d’ antenne Wi-Fi comme indiqué ci-dessous. 2. Placez les antennes le plus haut possible. Panneau arrière Entrée/ Sortie...
  • Seite 103: Vue D' Ensemble Des Composants

    Vue d’ ensemble des composants DIMMA2 CPU_PWR1 DIMMA1 Socket DIMMB2 CPU_FAN1 processeur DIMMB1 SYS_FAN1 PUMP_FAN1 ATX_PWR1 JUSB4 M2_2 JUSB3 PCIE_PWR1 PCI_E1 BIOS_SW1 SATA▼1▲2 M2_1 SATA▼3▲4 PCI_E2 SATA▼5▲6 BAT1 PCI_E3 SATA▼7▲8 JBAT1 JLED1 JUSB1 JUSB2 SYSFAN3 SYSFAN2 JFP1 JAUD1 JCI1 JFP2 POWER1 JTPM1 Vue d’...
  • Seite 104: Socket Processeur

    électrique. Veuillez garder le capot de protection du processeur après l’ installation du processeur. Selon les exigences de RMA (Return Merchandise Authorization), MSI n’ acceptera pas les cartes mère dont le capot de protection aura été retiré.
  • Seite 105: Slots Dimm

    Slots DIMM DIMMA2 DIMMB2 Canal A Canal B DIMMA1 DIMMB1 Installation recommandée de module mémoire DIMMB1 DIMMB1 DIMMB2 DIMMA1 DIMMA1 DIMMA1 DIMMA2 Important Pour garantir la stabilité du système au mode de double canal, assurez-vous d’ installer les modules de mémoire du même type et de la même densité en mode double canal.
  • Seite 106: Pci_E1~3: Slots D' Extension Pcie

    PCI_E1 pour profiter de performances optimales. Si vous installez une carte graphique lourde, il vous faut utiliser un outil comme la barre de support MSI Gaming Series pour supporter son poids et pour éviter la déformation du slot.
  • Seite 107: M2_1~2: Slots M.2 (Touche M)

    M2_1~2: Slots M.2 (Touche M) Important La technologie Intel RST supporte seulement un SSD ® M.2 PCIe avec une mémoire ROM UEFI. Intel Optane™ Memory Ready pour tous les slots M.2. ® Vidéo de démonstration M2_2 Référez-vous à la vidéo d’ instruction sur M2_1 l’...
  • Seite 108: Sata1~8: Connecteurs Sata 6 Gb/S

    SATA1~8: Connecteurs SATA 6 Gb/s Ces connecteurs utilisent une interface SATA 6 Gb/s. Chaque connecteur peut être relié à un appareil SATA. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 SATA8 SATA7 Important Veuillez ne pas plier les câbles SATA à 90° car cela pourrait entraîner une perte de données pendant la transmission.
  • Seite 109 Combinaison des slots M.2 2 x M.2 PCIe + 8 x SATA 1 x M.2 SATA + 1 x M.2 PCIe + 7 x SATA M.2 PCIe M.2 SATA 1 x M.2 PCIe + 1 x M.2 SATA + 7 x SATA 2 x M.2 SATA + 6 x SATA M.2 PCIe M.2 SATA...
  • Seite 110: Cpu_Pwr1, Atx_Pwr1, Pcie_Pwr1: Connecteurs D' Alimentation

    CPU_PWR1, ATX_PWR1, PCIE_PWR1: Connecteurs d’ alimentation Ces connecteurs vous permettent de relier une alimentation ATX. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V...
  • Seite 111: Jfp1, Jfp2: Connecteurs De Panneau Avant

    Notez que les câbles d’ alimentation et de terre doivent être branchés correctement afin d’ éviter d’ endommager la carte. Pour recharger votre iPad, iPhone et iPod par l’ intermédiaire d’ un port USB, veuillez installer l’ utilitaire MSI SUPER CHARGER. ®...
  • Seite 112: Jusb1~2: Connecteurs Usb 2.0

    JUSB1~2: Connecteurs USB 2.0 Ces connecteurs vous permettent de relier des ports USB 2.0 sur le panneau avant. USB0- USB1- USB0+ USB1+ Ground Ground No Pin Important Notez que les broches VCC et Terre doivent être branchées correctement afin d’ éviter tout dommage sur la carte mère.
  • Seite 113: Cpu_Fan1, Pump_Fan1, Sys_Fan1~3: Connecteurs Pour Ventilateurs

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~3: Connecteurs pour ventilateurs Les connecteurs pour ventilateurs peuvent être utilisés en mode PWM (Pulse Width Modulation) et en mode DC. En mode PWM, les connecteurs fournissent une sortie de 12V constante et ajustent la vitesse des ventilateurs avec un signal de contrôle de vitesse.
  • Seite 114: Jci1: Connecteur Intrusion Châssis

    JCI1: Connecteur intrusion châssis Ce connecteur est relié à un câble d’ interrupteur intrusion châssis. Normal Commencer l’ activité intrusion châssis (défaut) Utilisation du détecteur d’ intrusion châssis 1. Reliez le connecteur JCI1 à l’ interrupteur ou au capteur d’ intrusion châssis situé sur le boîtier du PC.
  • Seite 115: Bios_Sw1: Interrupteur Multi-Bios

    BIOS en suivant les étapes suivantes. Avant la restauration, veuillez télécharger la dernière version de BIOS compatible à votre carte mère sur le site MSI. Ensuite, enregistrez le fichier BIOS sur la racine de la clé USB. 1. Eteignez l’ ordinateur.
  • Seite 116: Jbat1: Cavalier Clear Cmos (Réinitialisation Bios)

    JBAT1: Cavalier Clear CMOS (Réinitialisation BIOS) Une mémoire CMOS est intégrée et est alimentée en externe par une batterie située sur la carte mère afin de conserver les données de configuration système. Si vous souhaitez nettoyer la configuration système, placez le cavalier sur Effacer CMOS de manière à...
  • Seite 117: Jled1: Connecteur Led Rgb

    Avant d’ installer ou de retirer le ruban LED, veillez à toujours éteindre l’ alimentation et à débrancher le câble d’ alimentation de la prise électrique. Veuillez utiliser les logiciels de MSI pour contrôler le ruban d’ extension LED. Vue d’ ensemble des composants...
  • Seite 118: Indicateurs Led Embarqués

    Indicateurs LED embarqués EZ Debug LEDs Ces LED indiquent l’ état des composants clés au cours du processus de démarrage. En cas d’ erreur, la LED correspondante reste allumée jusqu’ à ce que le problème soit résolu. CPU - indique que le CPU n’ est pas détecté ou que son initialisation a échoué...
  • Seite 119: Configuration Du Bios

    Menu, F11 to enter Boot Menu” sur l’ écran, veuillez appuyer sur la touche Suppr. y Quand l’ ordinateur est déjà en marche, vous pouvez utiliser l’ application MSI FAST BOOT. Cliquez sur le bouton GO2BIOS puis sur OK. Le système redémarre et entre dans l’...
  • Seite 120: Réinitialiser Le Bios

    Avant la mise à jour : Veuillez télécharger la dernière version de BIOS compatible à votre carte mère sur le site MSI. Ensuite, veuillez sauvegarder le nouveau BIOS sur le lecteur flash USB. Mettre le BIOS à jour : 1. Appuyez sur la touche Suppr pour entrer dans l’ interface Setup du BIOS pendant le processus de POST.
  • Seite 121: Ez Mode (Mode Simplifié)

    EZ Mode (mode simplifié) Le mode EZ vous fournit les informations basiques du système et vous permet de configurer les réglages de base. Si vous souhaitez configurer les réglages du BIOS, veuillez utiliser le mode Advanced en appuyant sur le switch Setup Mode (Interrupteur de modes de réglages) ou la touche de fonction F7.
  • Seite 122 y Langue - vous permet de choisir la langue du BIOS. y Informations du système - montre la vitesse et la tension du processeur et de la mémoire, la température du processeur et de la carte mère, le type de carte mère et de processeur, la capacité...
  • Seite 123: Advanced Mode (Mode Avancé)

    Advanced Mode (mode avancé) Appuyez sur le Setup Mode switch (interrupteur de modes de réglages) ou sur la touche de fonction F7 pour commuter entre le mode simplifié et le mode avancé. Interrupteur de Capture modes de réglages Interrupteur XMP Recherche d’...
  • Seite 124: Oc Menu (Menu Overclocking)

    OC Menu (menu overclocking) Ce menu est destiné aux utilisateurs avancés souhaitant overclocker leur carte mère. Important L’ overclocking manuel du PC n’ est recommandé que pour les utilisateurs avancés. L’ overclocking n’ est pas garanti et une mauvaise manipulation peut rendre nulle votre garantie et sévèrement endommager votre matériel.
  • Seite 125 f Misc Setting* Appuyez sur les touches Entrée et + ou - pour ouvrir ou fermer les 3 paramètres suivants, relatifs aux fonctionnalités du processeur. f EIST [Enabled]* Active ou désactive la technologie Enhanced Intel SpeedStep Technology. ® [Enabled] Active la technologie EIST pour ajuster la tension du processeur et de la fréquence du cœur de manière dynamique.
  • Seite 126 f DRAM Timing Mode [Link] Choisit le mode de latences mémoire. [Link] Ceci vous permet de configurer les latences DRAM pour tous les canaux de mémoire. [UnLink] Ceci vous permet de configurer les latences DRAM pour chaque canal de mémoire. f Advanced DRAM Configuration Appuyez sur la touche Entrée pour entrer dans le sous-menu.
  • Seite 127 f CPU Memory Changed Detect [Enabled]* Active ou désactive les messages d’ alerte système au démarrage suite au remplacement du processeur ou de la mémoire. [Enabled] Le système montre un message d'alerte pendant le démarrage et vous devez charger les réglages par défaut pour les nouveaux périphériques. [Disabled] Désactive cette fonction et garde les réglages BIOS actuels.
  • Seite 128 fIntel Virtualization Tech [Enabled] Active ou désactive la technologie Intel Virtualization. [Enabled] Active la technologie Intel Virtualization et autoriser une plate-forme visant à faire fonctionner plusieurs systèmes d'exploitation dans des partitions indépendentes. Le système peut fonctionner virtuellement comme des systèmes multiples. [Disabled] Désactive cette fonction.
  • Seite 129 fPackage C-State Limit [Auto] Ce menu permet de choisir un mode C-state du processeur pour économiser l’ énergie lorsque le système est en veille. Ce menu apparaît lorsque la fonction Intel C-State est activée. fCFG Lock [Enabled] Verrouille ou déverrouille la fonction MSR 0xE2[15], CFG lock bit. [Enabled] Verrouille le CFG lock bit.
  • Seite 130: Informations Sur Les Logiciels

    ® Installer les pilotes 1. Allumez l’ ordinateur sous Windows ® 2. Insérez le disque MSI Driver Disc dans le lecteur optique. ® 3. L’ outil d’ installation apparaît automatiquement. Il trouvera et listera tous les pilotes dont vous avez besoin.
  • Seite 131 Содержание Безопасное использование продукции ............2 Технические характеристики ................ 3 Задняя панель портов ввода/ вывода ............8 Таблица состояний индикатора порта LAN ........... 8 Конфигурация портов Аудио ................8 Менеджер Realtek HD Audio ................9 Установка антенн (для версии AC) ..............11 Компоненты...
  • Seite 132: Безопасное Использование Продукции

    Безопасное использование продукции y Компоненты, входящие в комплект поставки могут быть повреждены статическим электричеством. Для успешной сборки компьютера, пожалуйста, следуйте указаниям ниже. y Убедитесь, что все компоненты компьютера подключены должным образом. Ослабленные соединения компонентов могут привести как к сбоям в работе, так и полной неработоспособности компьютера. y Чтобы...
  • Seite 133: Технические Характеристики

    2400/ 2133 МГц* y Поддержка Intel Extreme Memory Profile (XMP) ® * Для получения последней информации о памяти, пожалуйста, посетите сайт http://www.msi.com y 3x слота PCIe 3.0 x16 Слоты ƒ Поддержка режима работы x16/ x0/ x0, x8/ x8/ x0 расширения...
  • Seite 134 информации о использовании комбинаций портов M.2 и SATA. ** Обратитесь к Руководству по установке памяти Intel на сайте Optane ® ™ www.msi.com Чипсет Intel X299 ® y Поддержка RAID 0, RAID 1, RAID 5 и RAID 10 для накопителей SATA RAID y Поддержка...
  • Seite 135 Продолжение с предыдущей страницы y 1x 24-контактный разъем питания ATX y 1x 8-контактный разъем питания ATX 12В y 1x 6-контактный разъем питания ATX 12В y 8x разъемов SATA 6ГБ/с y 2x разъема M.2 (Ключ M) y 1x разъем M.2 (Ключ E) y 2x разъема...
  • Seite 136: Программное Обеспечение

    X-BOOST Программное y MYSTIC LIGHT обеспечение y RAMDISK y Network Manager y DPC Latency Tuner y FAST BOOT y CPU-Z MSI GAMING y Intel Extreme Tuning Utility ® y Google Chrome , Google Toolbar, Google Drive ™ y Norton Internet Security Solution ™...
  • Seite 137 ƒ Mystic light SYNC ƒ EZ DEBUG LED y Защита Эксклюзивные ƒ PCI-E Steel Armor функции MSI y Производительность ƒ Multi GPU – SLI Technology ƒ Multi GPU – CrossFire Technology ƒ DDR4 Boost ƒ USB с интерфейсом type A+C ƒ...
  • Seite 138: Задняя Панель Портов Ввода/ Вывода

    Задняя панель портов ввода/ вывода Разъемы антенны WiFi Порты Аудио (для версии AC) PS/2 мыши USB 2.0 Оптический PS/2 клавиатуры USB 3.1 Gen2 USB 3.1 Gen1 Type-C S/PDIF-Out Type-A USB 3.1 Gen2 USB 3.1 Gen1 Type-A Type-A Таблица состояний индикатора порта LAN Подключение/ Работа...
  • Seite 139: Менеджер Realtek Hd Audio

    Менеджер Realtek HD Audio После установки драйвера Realtek HD Audio, в системном трее появится значок Realtek HD Audio Manager. Дважды щелкните по значку для запуска приложения. Выбор устройства Расширенные настройки Состояние Дополнительные разъемов эффекты Мастер- Настройки громкость подключений Профили y Выбор устройства - позволяет выбрать источник аудио выхода и изменить соответствующие...
  • Seite 140 Подключение наушников и микрофона Подключение внешнего стерео усилителя (колонок) AUDIO INPUT Подключение звуковой системы 7.1 AUDIO INPUT Rear Front Side Center/ Subwoofer Задняя панель портов ввода/ вывода...
  • Seite 141: Установка Антенн (Для Версии Ac)

    Установка антенн (для версии AC) 1. Прикрутите антенны к разъемам антенны WiFi, как показано на рисунке ниже. 2. Поместите антенны как можно выше. Задняя панель портов ввода/ вывода...
  • Seite 142: Компоненты Материнской Платы

    Компоненты материнской платы DIMMA2 CPU_PWR1 DIMMA1 Процессорный сокет DIMMB2 CPU_FAN1 DIMMB1 SYS_FAN1 PUMP_FAN1 ATX_PWR1 JUSB4 M2_2 JUSB3 PCIE_PWR1 PCI_E1 BIOS_SW1 SATA▼1▲2 M2_1 SATA▼3▲4 PCI_E2 SATA▼5▲6 BAT1 PCI_E3 SATA▼7▲8 JBAT1 JLED1 JUSB1 JUSB2 SYSFAN3 SYSFAN2 JFP1 JAUD1 JCI1 JFP2 POWER1 JTPM1 Компоненты...
  • Seite 143: Процессорный Сокет

    Перед установкой или заменой процессора, необходимо отключить кабель питания. Пожалуйста, сохраните защитную крышку процессорного сокета после установки процессора. Любые возможные гарантийные случаи, связанные с работой материнской платы, MSI будет рассматривать только, при наличии ® защитной крышки на процессорном сокете. При установке процессора обязательно установите процессорный...
  • Seite 144: Слоты Dimm

    Слоты DIMM DIMMA2 DIMMB2 Канал A Канал B DIMMA1 DIMMB1 Рекомендации по установке модулей памяти DIMMB1 DIMMB1 DIMMB2 DIMMA1 DIMMA1 DIMMA1 DIMMA2 Внимание! Для более стабильной работы системы в двухканальном режимах, модули памяти должны быть одинакового типа, количества и емкости. Для каждого канала, установка...
  • Seite 145: Pci_E1~3: Слоты Расширения Pcie

    Для установки одной карты расширения PCIe x16 с оптимальной производительностью рекомендуется использовать слот PCI_E1. При установке массивной видеокарты, необходимо использовать такой инструмент, как MSI Gaming Series Graphics Card Bolster для поддержки веса графической карты и во избежание деформации слота. Перед установкой или извлечением плат расширения убедитесь, что...
  • Seite 146: M2_1~2: Разъемы M.2 (Ключ M)

    M2_1~2: Разъемы M.2 (Ключ M) Внимание! RST только поддерживает PCIe M.2 SSD с UEFI Intel ® ROM. Память Intel Optane™ Memory совместима с ® любыми слотами M.2. Видео Инструкция M2_2 Смотрите видео, чтобы узнать как M2_1 установить модуль M.2. http://youtu.be/JCTFABytrYA Установка...
  • Seite 147: Sata1~8: Разъемы Sata 6 Гб/С

    SATA1~8: Разъемы SATA 6 Гб/с Эти разъемы представляют собой интерфейсные порты SATA 6 Гб/с. К каждому порту можно подключить одно устройство SATA. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 SATA8 SATA7 Внимание! Избегайте перегибов кабеля SATA под прямым углом. В противном случае, возможна...
  • Seite 148 Разъемы М.2 и различные возможные примеры использования 2xM.2 PCIe+ 8xSATA 1xM.2 SATA+ 1xM.2 PCIe+ 7xSATA M.2 PCIe M.2 SATA 1xM.2 PCIe+ 1xM.2 SATA+ 7xSATA 2xM.2 SATA+ 6xSATA M.2 PCIe M.2 SATA Компоненты материнской платы...
  • Seite 149: Cpu_Pwr1, Atx_Pwr1, Pcie_Pwr1: Разъемы Питания

    CPU_PWR1, ATX_PWR1, PCIE_PWR1: Разъемы питания Данные разъемы предназначены для подключения блока питания ATX. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground +12V...
  • Seite 150: Jfp1, Jfp2: Разъемы Передней Панели

    USB3_RX_DN USB2.0+ Power No Pin Внимание! Помните, что во избежание повреждений, необходимо правильно подключать контакты питания и земли. Для того, чтобы зарядить ваш iPad, iPhone и iPod через порты USB, пожалуйста, установите утилиту MSI SUPER CHARGER. ® Компоненты материнской платы...
  • Seite 151: Jusb1~2: Разъемы Usb 2.0

    JUSB1~2: Разъемы USB 2.0 Данные разъемы предназначены для подключения портов USB 2.0 на передней панели. USB0- USB1- USB0+ USB1+ Ground Ground No Pin Внимание! Помните, что во избежание повреждений, необходимо правильно подключать контакты VCC и земли. JTPM1: Разъем модуля TPM Данный...
  • Seite 152: Cpu_Fan1, Pump_Fan1, Sys_Fan1~3: Разъемы Вентиляторов

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~3: Разъемы вентиляторов Modulation) управлением и управлением постоянным током. Разъемы вентиляторов с PWM управлением имеют контакт с постоянным напряжением 12В, а также контакт с сигналом управления скоростью вращения. Управление скоростью вращения вентиляторов с управлением постоянным током, осуществляется через соответсвующие разъемы путем изменения величины напряжения.
  • Seite 153: Jci1: Разъем Датчика Открытия Корпуса

    JCI1: Разъем датчика открытия корпуса К этому разъему подключается кабель от датчика открытия корпуса. Нормально Разрешить запись по событию (По умолчанию) открытия корпуса Использование датчика открытия корпуса 1. Подключите датчик открытия корпуса к разъему JCI1. 2. Закройте крышку корпуса. 3. Войдите в BIOS > SETTINGS > Security > Chassis Intrusion Configuration. 4.
  • Seite 154: Bios_Sw1: Переключатель Multi-Bios

    В случае “неудачного” обновления BIOS, когда система перестала загружаться, вы можете восстановить BIOS, следуя указаниям ниже. Перед восстановлением, скачайте с сайта MSI последнюю версию файла BIOS, который соответствует вашей модели материнской платы. Сохраните файл BIOS в корневую папку USB флэшки.
  • Seite 155: Jbat1: Джампер Очистки Данных Cmos (Сброс Bios)

    JBAT1: Джампер очистки данных CMOS (Сброс BIOS) На плате установлена CMOS память с питанием от батарейки для хранения данных о конфигурации системы. Для сброса конфигурации системы (очистки данных CMOS памяти), воспользуйтесь этим джампером. Сохранение данных Очистка данных/ Сброс BIOS (По умолчанию) Сброс...
  • Seite 156: Jled1: Разъем Rgb Led

    что длина лент должна быть не более 2 метров, иначе яркость свечения будет падать. Перед установкой или заменой светодиодных лент RGB, необходимо полностью обесточить систему и отключить кабель питания. Используйте утилиту MSI для управления удлинительными ® светодиодными лентами. Компоненты материнской платы...
  • Seite 157: Встроенные Индикаторы

    Встроенные индикаторы Индикаторы отладки EZ Данные светодиоды показывают состояния основных компонентов в процессе загрузки. При возникновении ошибки, соответствующий светодиод продолжает гореть до устранения проблемы. CPU - процессор не обнаружен или поврежден. DRAM - память DRAM не обнаружена или повреждена. VGA - видеокарта не обнаружена или повреждена.
  • Seite 158: Настройка Bios

    Нажмите клавишу Delete, когда появляется сообщение на экране Press DEL key to enter Setup Menu, F11 to enter Boot Menu во время загрузки. y При помощи приложения MSI FAST BOOT. Нажмите на кнопку GO2BIOS и выберите ОК. Система перезагрузится и автоматически войдет в настройки...
  • Seite 159: Сброс Bios

    обратитесь к разделу “Джампер/ Кнопка очистки данных CMOS” . Обновление BIOS Обновление BIOS при помощи M-FLASH Подготовительные операции: Пожалуйста, скачайте последнюю версию файла BIOS с сайта MSI, который соответствует вашей модели материнской платы. Сохраните файл BIOS на флэш-диске USB. Обновление BIOS: 1.
  • Seite 160: Режим Ez

    Режим EZ Режим EZ предоставляет основную информацию о системе и позволяет выполнить основные операции по настройке. Для настройки расширенных функций BIOS, пожалуйста, войдите в Расширенный режим, путем нажатия Переключатель режимов установки или при помощи функциональной клавиши F7. Переключатель режимов установки Переключатель...
  • Seite 161 y Язык - позволяет выбрать язык интерфейса настроек BIOS. y Информация о системе - показывает частоту процессора/ памяти, температуру процессора/ материнской платы, информацию о материнской плате/процессоре, размер памяти, напряжение на процессоре/ памяти, версию BIOS и дату создания. y Приоритет загрузочных устройств - вы можете переместить инонку устройства...
  • Seite 162: Режим Разгона

    Режим разгона Нажмите переключатель режимов установки или функциональную клавишу F7 для переключения между режимами EZ и разгона в настройках BIOS. Переключатель режимов установки Переключатель XMP Скриншот Поиск Язык Информация о системе Переключатель Приоритет OC GENIE 4 загрузочных устройств Выбор меню Выбор...
  • Seite 163: Меню Oc

    Меню OC Данное меню предназначено для опытных пользователей и предоставляет возможности для «разгона» системы. Внимание! Разгонять ПК вручную рекомендуется только опытным пользователям. Производитель не гарантирует успешность разгона. Неправильное выполнение разгона может привести к аннулированию гарантии и серьезному повреждению оборудования. Неопытным пользователям рекомендуется использовать функцию OC GENIE 4.
  • Seite 164 f Adjusted Ring Frequency Установка множителя кольцевой шины. Это значение нельзя изменять. f Misc Setting* Нажмите клавишу Enter, + или -, чтобы включить или выключить следующие 3 пункта, связанные с характеристиками процессора. f EIST [Enabled]* Включение или выключение технологии Enhanced Intel SpeedStep.
  • Seite 165 f Memory Try It ! [Disabled] Позволяет улучшить совместимость памяти и производительность, путем выбора наиболее оптимального пресета. f DRAM Timing Mode [Link] Режимы таймингов памяти. Позволяет пользователю настроить тайминги DRAM вручную [Link] для всех каналов памяти. Позволяет пользователю настроить тайминги DRAM вручную [UnLink] для...
  • Seite 166 f PCH Voltages control [Auto] (optional) Эти параметры позволяют вам задать напряжения, связанные с PCH. При установке в Auto, BIOS установит напряжения автоматически. Вы также можете настроить напряжения вручную. f CPU Memory Changed Detect [Enabled]* Включение или выключение предупреждающих сообщений при загрузке системы, когда...
  • Seite 167 fLimit CPUID Maximum [Disabled] Включение или выключение расширенных значений CPUID. BIOS будет ограничивать максимальное входное значение [Enabled] CPUID для обхода проблемы загрузки в устаревших операционных системах, не поддерживающих процессор с расширенными значениями CPUID. Используйте фактическое максимальное входное значение [Disabled] CPUID. fIntel Virtualization Tech [Enabled] Включение...
  • Seite 168 fIntel C-State [Auto] Включение или выключение Intel C-State. C-State является технологией управления питанием процессора, определенной ACPI. Параметр будет настроен автоматически с помощью BIOS. [Auto] Определяет состояние простоя системы и значительно [Enabled] сокращает энергопотребление процессором. Выключение функции. [Disabled] fC1E Support [Disabled] Включение...
  • Seite 169 fShort Duration Power Limit (W) [Auto] Настроить предельную мощность TDP процессора при кратковременных нагрузках в режиме Turbo Boost. fCPU Current Limit (A) [Auto] Устанавливает максимальное ограничение по току для процессора в режиме Turbo Boost. В случае превышения установленного значения, процессор автоматически снижает частоту ядер. fFCLK Frequency [Auto] Устанавливает...
  • Seite 170: Описание Программного Обеспечения

    7. Следуйте инструкциям на экране, чтобы установить Windows ® Установка драйверов 1. Загрузите компьютер в Windows ® 2. Вставьте диск с драйверами MSI Driver Disc в привод для оптических ® дисков. 3. Автоматически отобразится окно установщика, который найдет и перечислит все необходимые драйверы.
  • Seite 171: Regulatory Notices

    The point of contact for regulatory matters is MSI, recycling and disposing of their end-of-life products. MSI-NL Eindhoven 5706 5692 ER Son. y Visit the MSI website and locate a nearby distributor B급 기기 (가정용 방송통신기자재) for further recycling information.
  • Seite 172 MSI will comply with the product take entregar a una empresa autorizada para la recogida de back requirements at the end of life of MSI-branded estos residuos.
  • Seite 173 及醫療用電波輻射性電機設備之干擾 。 saranno obbligati a ritirare ogni prodotto alla fine del suo ciclo di vita. MSI si adeguerà a tale Direttiva Products with radio functionality (EMF) ritirando tutti i prodotti marchiati MSI che sono stati This product incorporates a radio transmitting venduti all’interno dell’Unione Europea alla fine del...
  • Seite 174 Alternatively, please try the following help resources for further guidance. y Visit the MSI website for technical guide, BIOS updates, driver updates, and other information: http://www.msi.com y Register your product at: http://register.msi.com...

Diese Anleitung auch für:

X299m-a pro ac

Inhaltsverzeichnis
