en
b) AL-KO overrun device:
Coupling Draw-
type bar
tube
Ø
AK 160 (A) 35
AK 160 (B) 50
AK 300
AKS 1300
Removing the available fixing screws
ADVICE
Please note the following before re-
moving the fixing screws!
The shock absorber is hooked onto
fixing screw (7-1) for most overrun
devices.
CAUTION!
The overrun device shock absorber will
pull out on its own!
Use the supplied mounting bolts (Ø
10) for the installation
1. Remove the bellows from the hitch ball.
2. Undo and remove self-locking nuts from the
hexagon bolts.
3. Pull out and/or drive out hexagon bolt (7-2) .
4. Pull out and/or drive out hexagon bolt (7-1)
into mounting bolt (7-4) and leave the bolt in
the drawbar tube to centre the shock absor-
ber.
5. Remove the trailer hitch ball coupling (7-5) .
ADVICE
Reuse any attached spacers!
Installation of the anti-theft device
Cross screw connection
(for AL-KO overrun devices)
Attachment of parts according to figure (8)
Parts
Item 1 Locking plates left/right
10
Bellows
Installation without
change possible
Replace the bellows with
the one supplied.
Ventilation holes must
be at the bottom.
Attachment of parts according to figure (8)
Parts
Item 2 Hexagon socket screw M12 8.8 with
low profile head - DIN 7984
Item 4 Self-locking nut M12
Item 7 Spacer plate AK 160
ADVICE
Only use spacer plates part 7 with AK
160 with 50 mm drawbar!
Procedure
1. Push AK 300 / AK160 or AKS 1300 and, if re-
quired, spacers onto the drawbar tube so that
the attachment holes match.
2. Position any spacer sleeves in the drawbar
tube.
3. Attach fixing parts as shown in figure (8) .
4. During this process also thread on any spacer
sleeves in the drawbar tube (with front screw
- level).
5. Insert mounting bolt Ø 10 (with rear screw) ho-
rizontally.
Shock absorber is threaded on.
Cross-type screw fitting
(for other overrun devices)
Attachment of parts according to figure (9)
Parts
Item 1 Locking plates left/right
Item 2 Hexagon socket screw M12 8.8 with
low profile head - DIN 7984
Item 3 Special screw M12 8.8 with half-
round head
Item 4 Self-locking nut M12
Item 5 Fixing plate (two pieces)
Item 6 Profile plate *
Item 7 Spacer plate AK 160
* not included in the scope of delivery
Procedure
1. Push AK 300 / AK160 or AKS 1300 and, if re-
quired, spacers onto the drawbar tube so that
the attachment holes match.
