Main screen/ Value display
The Display shows the measured value of the internal sensor. The value of an external sensor will be shown if connected and
configured accordingly. The room thermostat controls in this case according to the external sensor.
Header
Current date and time will be displayed in the header. If enabled, ECO-mode status is indicated via symbol
An attention symbol can be displayed in the header. This symbol has a higher priority than the ECO-mode symbol and is
prefixed instead of this.
Footer
Depending upon the heating or cooling mode, occupancy or window contact status, the corresponding symbols will be shown in
the footer. The symbol "active timechannel" will be shown only if active.
Symbols
Occupancy
Window contact/dew point
Heating/Cooling
Fan Speed
Active timechannel
Systemair GmbH Germany
Header
Footer
info@systemair.de
Value display
....
