Features of transmitter

Steering Wheel

Steering Wheel rotates up to 35 degrees to the
right/left

Throttle Trigger

Pull the throttle trigger for running forward and push
it for breaking and running backward.
Steering Trim (ST. TRIM)
Rotate the trim to adjust the Steering Servo the
neutral position. When you adjust the position of
the Steering Servo, set the Steering Rate Adjuster
(ST.D/R) at the maximum position so that the
movement of the Steering Rate Adjuster is
maximized and therefore it easy to adjust.
Throttle Trim (TH. TRIM)
Move the trim tab to adjust the Throttle Servo (or
the Speed Controller) at the neutral position.
REFLEX WHEEL CARSON Radio Control System 500016/500017

Servo Reverse

27
FM
These Reverse Switches allow the rotation of the
servo(s) to be reversed. The servo(s) rotate(s)
clockwise at NOR position and rotate(s)
counterclockwise at REV position.
Steering Trim
Channel1
Throttle Trim
Channel2
Steering Reverse
Channel1
Throttle Reverse
Channel2
