Tool Specifications

Hand Circular Saw
Type
Power consumption
Rated rpm (no load)
Saw blade Diameter
Hole
Tooth width
Blade thickness 1.8 mm
Cutting depth 90°
45°
Cutting angle
Weight (without accessories)
Protection class

Operating Controls

1 Lock-off switch
2 On/Off switch
3 Sawdust ejector/Connection neck for dust
extraction
4 Riving knife screw
5 Lever for swinging guard
6 Base plate
7 Swinging protective guard
8 Grip
9 Winged screw for cutting angle adjustment
10 Winged screw for parallel guide
11 Cutting mark
12 Winged screw for cutting depth adjustment
13 Scale
14 Parallel guide
15 Allen key
16 Ring spanner
17 Clamping screw
18 Washer
19 Clamping flange
20 Saw blade
21 Mounting flange
22 Riving knife
23 Motor spindle
Not all of the accessories illustrated or described are
included as standard delivery.

Intended Use

The machine is intended for cutting wood lengthways
and crossways in straight lines and at mitred angles of
up to 45° on a firm surface.
The user alone is responsible for any liabilities caused
by usage other than intended.
8
GB

Notes on Safety Prevention

CSP 55-2
1100 W
4700 rpm
160 mm
For further notes on safety refer to enclosed Sheet.
20 mm
The machine is not qualified for operation in envi-
2.8 mm
ronments where danger of explosion exists.
The machine must not be damp and must not be
0...55 mm
operated in a wet environment.
0...38 mm
Always inspect cable and plug before using
90°... 45°
machine. Only have damage repaired by a qualified
3.6 kg
professional.
II /
The machine must not be operated without the
appropriate safety devices.
Always use the riving knife.
The swinging protective guard must be able to
move freely and must not be jammed in the open
position.
Put the plug into the mains socket only when the
machine is switched off.
Wear safety glasses, hearing protectors and protec-
tive gloves.
The dust that is produced while working is detri-
mental to health. Use dust extraction and wear a
dust mask.
Do not work with materials containing asbestos.
Always hold the machine with both hands during
operation and make sure you have a firm foothold.
Always lay the cable away from the machine
towards the rear.
Clamp the work-piece if it cannot be secured by its
own weight.
Apply the machine to the material only after it has
been switched on.
The cutting path must be free of obstacles on the top
and the bottom.
Keep hands away from the rotating saw blade.
Be careful not to come in contact with the rotating
saw blade on the underside of the workpiece.
The saw blade should not protrude below the work-
piece more than 3 mm.
Do not cut into nails, screws, etc.
If the saw blade becomes jammed, switch off the
machine immediately.
Do not stop the saw blade after switching off with
side pressure.
Always remove the plug from the power supply
socket before carrying out any work on the
machine, when interrupting work and when not
using the machine.
Do not leave clamping tools inserted.
Do not carry the machine by the power cord.
Persons under 16 are not permitted to use the
appliance.
Safe operation of this machine is possi-
ble only when the operating instruc-
tions and the safety precautions are read
completely and the instructions contai-
ned therein are strictly observed.
