Technical Data

TECHNICAL DATA,
description
Pump RPM
Weight
Max dP
Nominal pressure
Max Q
Sound level of unit 1 m
66
Inlet/Outlet
* Standard DC Green System, Max
22 kPa
CAPACITY AND POWER CONSUMPTION
kPa Pu
6 0
6
50
8
40
4
30
2
20
1 0
0
200 400 600
6
10
4
2 0
30
kW P

Dimensions and Arrangements

2017-04-12
TPR 40
rpm 4000
kg 400
kPa 26*
kPa 20
m /h 1200
3
dB(A)
Ømm 160/160
7
5
3
1
800 1000 1200 1400
1
2
3
8
TPR 35, TPR 40, TPR 43, TPR 47, TPR 50
TPR 40, 15kW - 14
POWER RATING
PART NO/MOTOR Hz
230 V
400 V
460 V USA/CAN
575 V CAN
1. TPR 35 11 kW
2. TPR 40 15 kW
3. TPR 43 18,5 kW
4. TSR 43 18,5 kW
5. TPR 47 22 kW
6. TSR 47 22 kW
7. TPR 50 30 kW
8. TSR 50 30 kW
The capacity curves for Dustcontrol vacuum produ-
cers have been measured and are stated empirically.
Outlet pressure losses from a normal outlet (silencer,
back-fl ow valve/bend) have been accounted for in the
Q
curve. Additional equipment such as a diffuser can
3
m /h
1600
result in increased pressure loss and must be taken
into consideration.
5
Stated air-fl ows are for standard air
7
(101.3 kPa@ 20
The stated curves are for negative application, all
pressures stated are assumed to be below relative
atmospheric pressure at sea level. These devices can
also be used for positive pressure application and will
generate a greater pressure differential.
TPR 40
50 106802/15 kW
50 106800/15 kW
60 106805/20 HP
60 106806/20 HP
o
C).
Part No 9045-A
