Packing List; Installation - Swim & Fun Easy pH Bedienungsanleitung

UK
2

PACKING LIST

1)
1) Controller box
2) Fixing support and kit
3) 2 saddles
4) 1 pH probe
5) 5 meter semi flexible tubing
3

INSTALLATION

Important
Before proceeding with the installation of the device, it is very important to check the
following points:
• The installation area should be dry and properly ventilated, protected from rain, splashes, water
spray, and UV radiation.
• Ensure that the pH corrector product container is kept in a place sufficiently remote from any
electrical equipment and any other chemical products. Failure to comply with this instruction will
lead to abnormal oxidation of the metallic parts which could result in complete breakdown of the
device.
• The assembly of the device and its accessories must be performed strictly in compliance wit the
following layout diagram.
The device is designed to work only in acid mode (pH minus injection).
MV-1815-12-2017 . © All rights reserved Swim & Fun Scandinavia ApS
2) 3) 4) 5) 6)
6) 1 suction strainer
7) 1 injection connector Ø 1/2"
8) 1 probe holder Ø 1/2"
9) 1 plug for probe calibration
7) 8) 9)
