Operating instruction
GENERAL DESCRIPTION
1. Pusher
2. Lid
3. Lock button
4. Control knob (On, Off, R)
5. Main body
6. Juice spout
7. Juicer collector
8. Juice jug
8a. Pulp container
9. Container lid
10. Pulp spout
11. End lid
12. Filtr
13. Extracting bolt
14. Feeding tube
10
TECHNICAL DATA
- power: 200W
- mains voltage: 230V ~ 50Hz
- maximum time
of continuous operation: 10 minutes
- break before continuation
of operation: 10 minute
HOW TO USE THE APPLIANCE
PERFECT JUICER is designed for processing most of fruits and vegetables in a more efficient way than traditional
juicer.
Before using the appliance
- Read these instructions for use carefully before using the appliance
- make sure that none of elements are demaged
- wash all detachable parts,
- assemble the appliance
Montage
- Place the juice collector (7) into main body (5) and turn left
- In juicer collector (7) set: Extracting bolt (13), filter (12) and pokrywa końcowa(11) (rys.2-4),
- set the containers (8,8a) under the spouts (6,10) (pic. 7)
- on the feeding tube(14) put the lid (2) according with the indicators
- Slide the pusher (1) into the feeding tube(14) in the lid (2) (pic. 6).
Do not turn on the appliance if some of the moving parts are not installed
Perfect Juicer PJ200
11
12
9
8
14
13
8a
7
7
GB
1
6
2
3
4
5
