4. Technical data

Mains voltage: ................................230V ~ 50 Hz
Rated input current ................................... 0.45 A
Power rating: ............................................... 84 W
Rated out- 6 V d.c.
put voltage
Rated out- 5.6 A arith.
put current 8 A eff .
" "
Rated out- 0.55 A
put current arith.
" " 0.85 A eff .

5. Before starting the equipment

Most motor vehicle manufacturers recom-
mend that the battery should be discon-
nected from the vehicle's electrical system
before being charged. We would like to point
out that even standard vehicles are fi tted with
a whole host of electronic equipment (such
as ABS, ASR, injection pump and on-board
computer). Any voltage peaks that occur may
cause defects in these electronic modules.
Therefore the battery should be disconnec-
ted from the electrical system before being
charged.
Please also refer to the instructions in the
owner's manuals for the car, radio, navigation
system, etc.
5.1 Charging the battery:
•
Release or remove the battery stoppers (if
fitted) from the battery.
•
Check the acid level in the battery. If neces-
sary, top up the battery with distilled water (if
possible). Important. Battery acid is aggres-
sive. Rinse off any acid splashes thoroughly
with lots of water and seek medical advice if
necessary.
•
Figure 2: Select the charging voltage. Pay
particular attention to the voltage details on
the battery you wish to charge. Select the
charging current on the basis of the symbols.
•
First connect the red charging cable to the
positive pole of the battery.
•
Then connect the black charging cable to the
bodywork of the vehicle away from the battery
and the petrol pipe.
•
Warning! Under normal circumstances the
negative battery pole is connected to the
Anl_CC_BC_8_SPK1.indb 13 Anl_CC_BC_8_SPK1.indb 13
GB
12 V d.c
•
4.6 A arith. 20-120 Ah
6.5 A eff .
0.8 A arith. 3,7-30 Ah
1,2 A eff .
Calculating the charging time (Figure 3)
The charging time depends on the charge status
of the battery. If the battery is fully discharged,
the approximate charging time can be calculated
using the following formula:
Charging time/h =
Example =
A high initial current, approximately equal to the
rated current will fl ow in a normally discharged
battery. As the charging time increases, the char-
ging current will fall.
Old batteries for which the charging current does
not fall are suff ering from a defect, such as a cell
short circuit or ageing damage.
The charging current should be 1/10 to 1/6 of the
battery capacity.
Important! Do not exceed the charging time.
After the end of the charging time pull the plug out
of the socket and disconnect the charger from the
battery.
A high charge can only be identifi ed by measuring
the acid density using an acid tester. Note! Gases
are released during the charging process (bub-
bles will form on the surface of the battery fl uid). It
is essential that you ventilate the rooms well.
- 13 -
bodywork and you proceed. In exceptional
cases it is possible that the positive battery
pole is connected to the bodywork (positive
earthing). In this case connect the black
charging cable to the negative pole on the
battery. Then connect the red charging cable
at a point away from the battery and the petrol
pipe.
After the battery has been connected to the
charger, you can connect the charger to a
socket supplying 230V~50Hz. Do not connect
it to a socket that supplies any other mains
voltage. Important. Charging may create
dangerous explosive gas and therefore you
should avoid spark formation and naked fla-
mes whilst the battery is charging. There is a
risk of explosion!
Battery capacity in Ah
Amp. (arithmetic charging
current)
24 Ah
= 9,6 h max.
2,5 A
