2. INSTALLATION RECOMMANDATIONS
This appliance must be installed in a way that it enables the heater to brew a
maximum air volume.
The appliance must be connected in a fixed horizontal position and in compliance
with legal regulations.
In Bathrooms, the panel must be installed in conformity with IEC 364-7-701:1984
and may be located in compliance with the picture 1 in the zones 2 and 3. The
panel is gadget of the class II and is protected against spraying water, protection
IP 24. The panel must not be located directly under mains outlet. Electrical installa-
tion is to be equipped with double pole switch, by which the distance of open
contacts is equal to min. 3 mm
IMPORTANT: « DO NOT COVER »
To avoid overheating, do not cover the heater in any circumstances.
The picture sticker « DO NOT COVER » reminds you of this risk.
It is strictly forbidden to cover or block the shades or air outlets in
order to avoid incidents or deterioration of the device. Please avoid
installation close to air outlets (chimneys, ventilation), behind curtains
or doors.
Please respect the minimum installation distances to the floor, walls,
furniture, etc ... (Picture B)
3. INSTALLATION AND WALL MOUNTING
Remove the bracket of the appliance using a screwdriver (Item 1). Attach the bracket to the wall using 4 screws (Ø 5, 5 mm max.) ensu-
ring the right direction and at the right height (Fig. C).
Typ 1000W
Axle base [mm]
H [mm]
B [mm]
C [mm]
1500W 2000W
248 405 525
257 257 257
145 275 270
270 270 270
