Hifonics Triton I Bedienungsanleitung Seite 21

MODEL
CHANNELS
CIRCUIT
OUTPUT POWER RMS 13,8 V
Watts @ 4 Ohms
Watts @ 2 Ohms
OUTPUT POWER MAX. 13,8 V
Watts @ 4 Ohms
Watts @ 2 Ohms
Frequency Range –3dB
Damping Factor
Signal-to-Noise Ratio
THD&N
Input Sensitivity
Input Impedance
X-Over Modes
Various Highpassfilter
Various Lowpassfilter
Bass Boost @ 50 Hz
Phase Shift
Bass Remote
Line Outputs RCA
Fuse Ratings
Dimensions
Width x Height x Length
OPTIONAL ACCESSORIES FOR HiFONICS TRITON AMPLIFIERS
You can simplify the installation of the high level speaker connections, if you use the separately available hi-to-lo adaptors
HF-HLA from HiFonics. You may find the adaptor at your car audio retailer.
With the HF-HLA you just need to connect the bared speaker cables in the regarding ports and connect the RCA jacks with LINE IN on
the amplifier.
Please ensure the correct polarity of the connections.
Usually the "+" positive cables are red or dark grey,
With one HF-HLA adaptor you are able to connect one channel pair,
this means for a mono ampilfier you need one adaptor.
Speaker Cables
–
R
+
Technical specifications are subject to change! Errors are reserved!
TRITON I
For damages on the vehicle and the device, caused by handling
1
errors of the device, we can't assume liability.
CLASS A/B Analog
All HiFonics Amplifiers are tagged with a individual serialnumber,
which will be registerd for statistic and service conditional purposes.
1 x 250
All HiFonics Amplifiers are tagged with a CE-Certification Mark.
1 x 450
Thereby these devices are ceritified for a use inside vehicles inside
the European Union (EU).
1 x 500
1 x 900
WARRANTY DISCLAIMER
20Hz - 30 kHz
> 800
The limited warranty comply with legal regulations. Failures or
> 90 dB damages caused by overload, improper use or by using the product
for competitions are not covered by the warranty.
0,05%
Please return the defective product only with a valid proof of purchase
6 - 0.2 V
and a detailed malfunction description.
> 47 kOhm
LPF/BPF - HPF - Full
10 - 100 Hz
50 - 250 Hz
0 - 12 dB
0 - 180°
BLC-TR
Fullrange
2 x 30 A
145 x 50 x 272 mm
+
L
–
SPECIFICATIONS |ENG
To the LINE IN on the Amp
21 25
26
