Motherboard Layout
1
17.0cm (6.7 in)
USB 2.0
T: USB0
64Mb
B: USB1
BIOS
19
18
CLRCMOS1
17
USB 2.0
CHA_FAN1
T: USB2
B: USB3
16
CPU_FAN1
USB 3.0
Top:
T: USB1
RJ-45
B: USB2
HD_AUDIO1
AUDIO
CODEC
1
SPI Flash Memory (64Mb)
2
SATA2 Connector (SATA_1, Black)
3
SATA3 Connector (SATA_0, Gray)
4
SATA2 Connector (SATA_2, Black)
5
SATA2 Connector (SATA_3, Black)
6
Intel B75 Chipset
7
USB 2.0 Header (USB4_5, Black)
8
System Panel Header (PANEL1, Black)
9
ATX Power Connector (ATXPWR1)
10
Consumer Infrared Module Header
(CIR1, Gray)
2
5 6
2
3
4
7 8
SATA_0
SATA_2
SATA_1
SATA_3
Intel
B75
CMOS
Battery
B75M-ITX
PCIE1
PCI Express 3.0
Front USB 3.0
15
11
12
13
14
15
16
17
18
19
ASRock B75M-ITX Motherboard
9
10
11
ATXPWR1
PLED PWRBTN
1
HDLED RESET
PANEL1
USB4_5
1
CIR1
1
USB3_3_4
RoHS
14
13
2 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Black)
USB 3.0 Header (USB3_3_4, Black)
1155-Pin CPU Socket
PCI Express 3.0 x16 Slot (PCIE1, Black)
Front Panel Audio Header
(HD_AUDIO1, Black)
CPU Fan Connector (CPU_FAN1)
Chassis Fan Connector (CHA_FAN1)
Clear CMOS Jumper (CLRCMOS1)
ATX 12V Power Connector (ATX12V1)
12
