EN
FILLING CLEAN WATER TANK
Be careful when removing water fill safety cap. Even if the cap can be unscrewed, the steam cleaner may still be
hot, especially the metal ring.
IMPORTANT: Do not add cleaning solution to the water tank.
Fig. 3
Fig. 4
REMOVING AND FILLING THE CLEANING AGENT TANK
IMPORTANT: Do not combine different cleaning agents together.
Fig. 5
Fig. 6
8 0
1. Place the steam cleaner on a level surface. If you fill the water tank
during or after use, see "Refilling Water During Operation" instructions.
After you have ensured the steam cleaner has cooled and pressure has
been released, the water fill safety cap should turn freely for removal.
Unscrew the water fill safety cap counter- clockwise (Fig. 3).
2. Add 300 ml of water into the measuring jug and pour the water
into the water tank (Fig. 4). (Max. capacity of the tank is 300 ml. Do not
overfill the water tank.)
3. Overfilling may cause excess water to be emitted from the steam cleaner.
When refilling the steam cleaner, make sure to empty all remaining
water from the water tank before refilling.
4. Re-install the water fill safety cap in a clockwise direction and tighten
until it is completely sealed.
5. DO NOT OVERTIGHTEN THE SAFETY CAP.
1. Squeeze the tabs on the sides of the cleaning solution tank to remove it
out of the steam cleaner as shown (Fig. 5).
2. Remove the cap from the top of the cleaning agent tank (Fig. 6).
3. Fill the cleaning agent tank with desired cleaning solution.
4. Install the cap back (Fig. 6).
5. Put the cleaning agent tank back by sliding it into its place. Apply light
pressure to the back of the tank until it clicks into the body of the steam
cleaner properly.
IMPORTANT: Do not leave the Cleaning agent regulator between the positions.
Make sure it clicks into a proper setting before use.
