Ambient Light Measurement

28
Before you start measuring, please attach the ambient light measuring head on the
limiting aperture of the i1Pro device. If you own multiple devices make sure that the
serial number on the ambient light measuring head matches the serial number of your
i1Pro device. The ambient light measuring head can also be used in conjunction with the
tripod holder.
1. The ambient light measuring head is stored in the bottom of the tripod holder.
To remove the ambient light measuring head, rotate the measuring head
counterclockwise until the arrow on the protection cover points to the
marking on the tripod holder.
2. Attach the ambient light measuring head on the limiting aperture of the i1Pro device.
The arrow on the protection cover must point to the
i1Pro device.
3. Rotate the ambient light measuring head clockwise until the arrow on the protection
cover points to the "locked" marking on the i1Pro device.
4. Pull off the protection cover from the ambient light head.
5. Configure your application software to ambient light measurement mode and press
the measurement button on the device to take measurements.
EN
"unlocked"
"unlocked" marking on the
