Access to the Video Controls

The controls for adjusting the video display are located on the front of the M1500SS
Display.
Figure 5 Video Display Controls

Adjusting the Viewing Angle

Turn the positive locking mechanism adjustment knob one quarter turn (horizontal to
vertical) to loosen. Adjust the M1500SS Display by pushing on the top front of the
display, then turn the adjustment knob a 1/4 turn back to lock in place.
Figure 6 Viewing Angle Adjustable from 0 up to 60 degrees
Note: When the adjustment knob is horizontal it is locked; when it is in the vertical
position it is unlocked.
Always maintain adequate ventilation to protect the display from overheating and to
ensure reliable and continued operation.
MENU
◄/Left
Microphone
