GEAR MOTOR RELEASE AND LOCK PROCEDURE
These two operations are required only in the event of a fault or power failure, and the user or assigned personnel must be
trained by the installer, who should provide a copy of these instructions to be kept with care together with the release key.
Before performing either of these procedures, ensure that the power supply is disconnected from the entire
automation, even in the event of a power failure.
RELEASE: 1) insert the key and turn anti-clockwise 2) pull the door to open it 3) pull and rotate the lever by approx. 120° to
release the motor; the gate leaf can now be moved manually. To keep the gate leaf locked in position, carry out the following
procedure.
Fig. R
1
3
BLOCCO: 4) richiudere la leva, il motoriduttore è bloccato e l'anta si può muovere solo elettricamente.
2
4
