EuroLine AKKU UP-4 HCL Spot WDMX Bedienungsanleitung Seite 37

12 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 255 0B FF 4% 100%
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 30 0B 1E 4% 12%
31 50 1F 32 12% 20%
51 70 33 46 20% 27%
71 90 47 5A 28% 35%
91 110 5B 6E 36% 43%
Control-channel 1 - Dimmer
F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 2 - Red
F Red (0=off, 255=100% red)
Control-channel 3 - Green
F Green (0=off, 255=100% green)
Control-channel 4 - Blue
F Blue (0=off, 255=100% blue)
Control-channel 5 - Amber
F Amber (0=off, 255=100% amber)
Control-channel 6 - White
F White (0=off, 255=100% white)
Control-channel 7 - UV
F UV (0=off, 255=100% UV)
Control-channel 8 - Strobe
S No function
F Strobe-effect with increasing speed
Control-channel 9 - Color presets
S No function
F RED 100% / GREEN increasing / BLUE 0%
F RED decreasing / GREEN 100% / BLUE 0%
F RED 0% / GREEN 100% / BLUE increasing
F RED 0% / GREEN decreasing / BLUE 100%
F RED increasing/ GREEN 0% / BLUE 100%
37/40
Feature
Feature
Feature
Feature
Feature
Feature
Feature
Feature
Feature
00088947.DOC, Version 1.1
