DMX-controlled operation

You can control the device individually via your DMX-controller. Every DMX-channel has a different
occupation with different features. The individual channels and their features are listed under DMX-protocol.
The device has three DMX channel modes. The Control Board allows you, as described above, to assign the
DMX channel mode.

Wireless DMX

For wireless data transmission you need a DMX-controller, a wireless transmitter and a wireless receiver or
devices with built-in wireless receiver. Please use the appropriate devices from the FUTURELIGHT range.
If a device with wireless receiver is connected to a DMX-controller via cable, the device will be controlled by
the cabled controller and not by the wireless transmitter.
The wireless receiver has an internal memory function. If the device is switched off and on again, the
receiver automatically logs onto the wireless transmitter.
The WDMX statuses are shown via the display of the device:
WDMX status
WDMX status dot is lit: The wireless receiver is logged into the wireless transmitter. The DMX signal is
present and received.
WDMX status dot flashes rapidly: The wireless receiver was logged into the wireless transmitter but the
WDMX transmitter is switched off or not connected to the power supply.
WDMX status dot flashes slowly: No DMX-signal, the wireless connection is on hold.
No WDMX status dot: Not logged into a wireless transmitter (free).
Function button: To log out a wireless receiver, press and hold the function button for 3 seconds.
Please note, that WDMX has priority over DMX.
The procedure for installing a wireless DMX system depends on the wireless transmitter being used. Please
refer to the instructions in the user manual of the corresponding device.

Addressing

The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the AKKU UP-4 HCL Spot WDMX will respond to the controller.
If you set, for example, the address in the 12 channel mode to channel 13, the AKKU UP-4 HCL Spot WDMX
will use the channel 13 to 24 for control.
Please, be sure that you don't have any overlapping channels in order to control each AKKU UP-4 HCL Spot
WDMX correctly and independently from any other fixture on the DMX-chain.
If several AKKU UP-4 HCL Spot WDMXs are addressed similarly, they will work synchronically.
For setting the desired starting address please press the MODE button until the display shows DMX 6-CH, 8-
CH or 12-CH. Press the ENTER button and the display shows: d001. Set the desired address via the UP or
DOWN buttons. Please press the ENTER button again to confirm.
Now you can start operating the AKKU UP-4 HCL Spot WDMX via your lighting controller.
